Supermicro X7DBU Motherboard Proprietary Socket T/Dual LGA 711

Price: SI $150.00

Product SKUsMBD-X7DBU-0

X7DBU

Physical StatsForm Factor

12" x 13" (30.5cm x 33.2cm)

Processor/CacheCPU

Dual 771-pin LGA Sockets
Supports up to twoIntel® 64-bit Xeon®processor(s) of the same
type below:

Quad-Core Intel®
Xeon®Processor
5400/5300 sequence
(Harpertown
/Clovertown processor)
up to 3.16 GHz
Dual-Core Intel®
Xeon®Processor 5200/5100/5000
sequence (Wolfdale
/Woodcrest/Dempsey processor)up to 3.40 GHz

System Bus

1333 / 1066 / 667 MHz system bus

Operating System Software

Supports 64-bit Operating Systems
Supports 32-bit Operating Systems

System MemoryMemory Capacity

Eight 240-pin DIMM sockets
Supports up to 32 GB 667 / 533MHz DDR2 ECC FB-DIMM memory
Dual branch memory bus
Memory must be populated in pairs
Memory Mirroring supported

Memory Type

667 / 533MHz FB-DIMM (Fully Buffered DIMM) ECC DDR2 SDRAM 72-bit, 240-pin gold-plated DIMMs

DIMM Sizes

256MB, 512 MB, 1GB, 2GB, 4GB

Memory Voltage

1.8V only
1.5V (AMB)

On-Board DevicesChipset

Intel® 5000P (Blackford) chipset
ESB2

Clock Generator

IDT CV152

SATA

Intel ESB2 SATA 3.0Gbps Controller
RAID 0, 1, 5, 10 support (Windows Only)
RAID 0, 1, 10 support (Linux)

IPMI

Support for Intelligent Platform Management Interface v.2.0
200-pin IPMI slot (SIMSO)
(Optional: AOC-SIMSO(+))
For Dedicated LAN, cable CBL-0177L must be used (cable sold separately)

Network Controllers

Intel® (ESB2/Gilgal) 82563EB Dual-port Gigabit Ethernet Controller

Graphics

ATI ES1000 controller with 16 MB of video memory

Super I/O

Winbond 83627HF chip

Input / OutputSerial ATA

Six Serial ATA ports

IDE

Single EIDE channel supports up to two UDMA IDE devices (IDE-M, IDE-S)
Supports UDMA Mode 5, PIO Mode 4, and ATA/100

Floppy

1 Floppy controller; 1.44 MB, 2.88 MB

LAN

2x RJ45 LAN ports

USB

2x USB rear ports
3x USB internal headers
Total 5 USB 2.0 Compliant / 1.1 Compliant

VGA

1x VGA Port

Keyboard / Mouse

PS/2 keyboard and mouse ports

Serial Port / Header

1 Fast UART 16550 serial port
1 Fast UART 16550 serial header

System BIOSBIOS Type

8Mb Flash EEPROM with Phoenix® BIOS

BIOS Features

Plug and Play (PnP)
SMBIOS 2.3
DMI 2.3
PCI 2.2
ACPI 1.0 / 2.0
USB Keyboard support

Chassis ( Optimized for X7DBU )1U Chassis

To ensure system stability, a 550W (minimum) ATX power supply
[4-pin (+12V), 8-pin (+12V) and 20-pin are required]

Expansion SlotsPCI-Express / PCI-X / UIO

1 (x8) PCI-Express&
1 UIO slot

1 64-bit 133MHz PCI-Xor
1 (x8) class="desc" style="font-weight: bold; margin-left: 0px; margin-bottom: 0px; padding-left: 0px; color: rgb(93, 139, 96) !important;">
Optional IPMI (Intelligent Platform Management Interface) 1.5 / 2.0
SuperDoctor® III
Watch Dog
NMI

Power Configurations

ACPI Power Management
Main Switch Override Mechanism
Wake-On-Ring (WOR) header
Wake-On-LAN (WOL) header
Power-on mode for AC power recovery
Internal / External modem remote ring-on

PC Health MonitoringVoltage

Monitors for CPU Cores, +1.8V, +3.3V, +5V, ±12V, +3.3V Standby, +5V Standby, VBAT, HT, Memory Voltage, Chipset Voltage
5-Phase-switching voltage regulator with auto-sense from 0.8375V-1.60V

FAN
