Enterprise Testing Conditions
Threat Prevention (Mbps)1 660
Next Generation Firewall2 1,300
IPS Throughput (Mbps) 1,400
Firewall Throughput (Mbps) 2,800
RFC 3511, 2544, 2647, 1242 Performance (LAB)
Firewall 1518 Byte UDP Packets (Mbps) 6,400
VPN AES-128 Throughput(Mbps) 2,600
Connections per Second 21,100
Concurennt Connections 500,000
Software
Security Firewall,VPN, User Awareness, QoS, Application Control, URL Filtering, IPS, Anti-Bot,Antivirus, Anti-Spam and SandBlast Threat Emulation (sandboxing)
Unicast, Multicast Routing OSPFv2,BGPv4 and 4++, RIP, PIM (SM, DM, SSM), IGMP
Mobile Access License (Users) 200 remote SNX or Mobile VPN client users
Hardware
WAN Port 1x10/100/1000Base-T RJ-45 port
DMZ Port 1x10/100/1000Base-T RJ-45 / 1x 1000BaseF SFP port (transceiver not included)
LAN Port 8x10/100/1000Base-T RJ-45 ports
Wi-Fi (optional) 802.11b/g/n and 802.11 n/ac wave II MIMO 4x4
Radio Band (association rate) Two radio bands concurrent: 2.4GHz (max 450 Mbps) and 5GHz (max1,700 Mbps)
3/4G/LTE (optional) 3/4G/LTEEmbedded modem, CAT6 with Main and Auxiliary antennas
SIM (optional) DualSIM (Nano and Micro)
Console Port 1xUSB-C
USB Port 1xUSB 3.0
SD Card Slot Micro-SDslot
Dimensions
Enclosure Desktop
Dimensions (W x D x H) 210x 170 x 42 mm, 8.3 x 6.7 x 1.7 in.
Weight 0.87 kg (1.9lbs.)
Environment
Operating / Storage 0ºC~ 40ºC / -45ºC ~ 60ºC (5~95%, non-condensing)
Power Requirements
AC Input 110– 240VAC, 50 – 60 Hz
Power Supply Rating 12V/3.3A40W power adapter (non-Wi-Fi), 12V/5A 60W power adapter (Wi-Fi and Wi-Fi-LTE)
Power Consumption (Max) 26.01(non-Wi-Fi); 31.28W (Wi-Fi); 35.5W (Wi-Fi-LTE)
Heat Dissipation 88.70(non-Wi-Fi); 100.66 (Wi-Fi), 106.73 (Wi-Fi-LTE); 121.06 (Wi-Fi-LTE)
Certifications
