Enterprise Testing Conditions

Threat Prevention (Mbps)1 450

Next Generation Firewall2 800

IPS Throughput (Mbps) 900

Firewall Throughput (Mbps) 1,000

RFC 3511, 2544, 2647, 1242 Performance (LAB)

Firewall 1518 Byte UDP Packets (Mbps) 2,000

VPN AES-128 Throughput(Mbps) 1,300

Connections per Second 14,000

Concurennt Connections 500,000

Software

Security Firewall,VPN, User Awareness, QoS, Application Control, URL Filtering, IPS, Anti-Bot,Antivirus, Anti-Spam and SandBlast Threat Emulation (sandboxing)

Unicast, Multicast Routing OSPFv2,BGPv4 and 4++, RIP, PIM (SM, DM, SSM), IGMP

Mobile Access License (Users) 100 remote SNX or Mobile VPN client users

Hardware

WAN Port 1x10/100/1000Base-T RJ-45 port

LAN Port 5x10/100/1000Base-T RJ-45 ports

Radio Band (association rate) One radio band non-concurrent: 2.4GHz (max 450 Mbps) or 5GHz(max 1,300 Mbps)

Console Port 1xUSB-C

USB Port 1xUSB 3.0

Dimensions

Enclosure Desktop,wall mount

Dimensions (W x D x H) 210x 160 x 37.5 mm, 8.3 x 6.3 x 1.5 in.

Weight 0.43 kg (0.95lbs.)

Environment

Operating / Storage 0ºC~ 40ºC / -45ºC ~ 60ºC (5~95%, non-condensing)

Power Requirements

AC Input 110– 240VAC, 50 – 60 Hz

Power Supply Rating 12V/3.3A40W power adapter

Certifications
