Model: WL-UG69DK1

• USB3.1 Gen1 Type-C and Type-A connectors compatible with Type-C/A laptops
• Built-in USB3.0 GPU, plug and display certified by DisplayLink
• 2 x DisplayPort++ (Dual Mode DisplayPort 1.2) and 2 x HDMI (Version 2.0) support resolution up to dual (4K)4096 x 2160@60Hz/(5k)5120x1440@60hz
• Support resolution (5K)5120 x 2880p60 when dual dp ports are connected
• Supports extend and mirror video modes. 5.1 channel surround sound through DisplayPort interface
• Gigabit Ethernet network RJ-45 backwards compatible with 10/100 Ethernet
• 2.0 Audio Line-out Jack for earphone and line-in Jack microphone
• 6 x USB3.0 ports compatible with all USB3.0 and USB2.0 devices

• Overview
• Specification
• Driver
• Q&A

One Dock Connects All

15 ports of incredible connectivity give you all your needs in a sleek, compact design.

Wavlink UG69DK1 supports dual 4K ultra 5K HD displays with one single cable, it will greatly help you work on high-resolution works, graphically intensive images, video editing, CAD drawings, medical images and so on.

WAVLINK USB-C ultra Universal Dock is a perfect companion for users who desire additional ports.

- 6 x SuperSpeed USB 3.0 ports

- 2 x 4K DisplayPorts

- 1 x Audio out

- 1 x USB-C in

- 2 x 4K HDMI

- 1 x Mic in

- 1 x Gigabit Ethernet

- 1 x 5k (DisplayPort + DisplayPort)

SuperSpeed USB 3.0 provides up to 5Gbps data transfer speeds, which is 10 times faster than USB 2.0. The WAVLINK UG69DK1 features 6 USB 3.0 ports, allowing for SuperSpeed data transfer between peripherals.

• 5Gb/s

  usb 3.0

• 480Mb/s

  usb 2.0

• Less than one minute to copy 3 hours of HDvideo

• Less than one minute to copy 3,000 photos

• Less than one minute to copy 1,200songs

Wired network connections are faster and more reliable than any Wi-Fi. The dock helps you tap into the full performance of wired network connections with built-in Gigabit Ethernet port.

The WAVLINK UG69DK1 allows you easily connect various devices at once, helping you keep your workspace organized and efficient at all times.

With separate microphone input and amplified audio output, you can enjoy crystal-clear conference calls or any other project that benefits from having your voice heard.

• TECHNICAL SPECIFICATIONS
• Model

  UG69DK1

• Ports

  6 x USB-A 3.0

  2 x DisplayPort

  2 x HDMI

  1 x USB-C

  1 x Audio Output Jack

  1 x Microphone Input Jack

  1 x RJ45 Gigabit Ethernet

  1 x DC Power Jack Port

• Button

  1 x Power ON/OFF Switch

• LED

  Blue

• Power Supply

  DC20V / 2A

• DIMENSIONS
• Unit Dimensions

  228mm x 80mm x 26mm ( L x W x H )

• Housing Material

  ABS

• Shell Color

  Black

• FUNCTIONS
• Working Standards

  Hub running at USB 3.0 speed

  DisplayPort resolution Max.4096 x 2160@60Hz

  Ethernet running at Gigabit

  2.0 Channel Audio

• Operating System Support

  Windows

  Mac OS X

• PACKAGE
• In The Box

  1 x USB-C Universal Docking station

  1 x USB 3.0 C to C Cable

  1 x USB 3.0 A to C Cable

  1 x DC20V Certified Power Adapter

  1 x User Manual
