Ethernet - Ports: 5 x RJ45, 10/100 Mbps, supports auto MDI/MDIX
- Standards: IEEE 802.3i, 802.3u, 802.3x, 802.3az
- Non-blocking Bandwidth: 1 Gbps
- MAC Table Size: 2K entries
- Jumbo Frames: 2048 2-pin industrial DC
- Input Voltage: 9-30 VDC
- PoE (Passive): Powered through ETH1 (9-30 VDC)
- Consumption: Idle 0.3W / Max 0.9W
Physical Interfaces - Ethernet: 5 x RJ45, 10/100 Mbps
- LEDs: 1 Power, 10 ETH status
- Power: 2-pin industrial DC
Physical Specifications - Material: Aluminum housing
- Dimensions: 113.1 x 27.4 x 80.5 mm
- Weight: 146.5 g
- Mounting: DIN rail, wall, flat surface (requires kit)
Operating Environment - Temperature: -40°C to 75°C
- Humidity: 5% to 95%, non-condensing
- Ingress Protection: CE, UKCA, EAC, FCC, IC, CB, RCM, CITC, ANRT, REACH, RoHS, WEEE
- Safety: EN IEC 62368-1:2020 + A11:2020, AS/NZS 62368.1:2022, IEC 62368-1:2018
- EMC Compliance: EN 55032:2015, EN 55035:2017, EN 61000-4 series
 |
|
