Components installed: Intel Core Ultra 7 265 Processor With Built In NPU Max 5.30 GHz, Default 32GB DDR5 5600 High Speed Memory 1DPC, 1TB NVMe PCIe 5.0 SSD, 1x 1000W Gold Level (90%) Power Supply, Windows 11 Pro Pre Loaded
Product SKUsSYS-C542i-11302USYS-C542i-11302U Gold Series version with pre-configured componentsMotherboardSuper C9B860-MWProcessorCPU

• Single LGA-1851
• Intel® Core™ Ultra (Series 2) U7-265, Max 5.30GHz

Core Count

• P-cores: 8C/20T; 30MB Cache
• E-cores: 12C/20T

Note

• Supports up to 65W TDP CPUs (Air Cooled)

System MemoryMemory

• Slot Count: 4 DIMM slots/2 Channels
• Max Memory (1DPC): 256GB 5600MT/s non-ECC DDR5 UDIMM
• View Memory Options

Memory Voltage

• 1.1V

On-Board DevicesSATA

• SATA (6Gbps)

Network Connectivity

• 1 RJ45 1GbE with Intel® PHY I219-V
• View AOC Options

Input / OutputLAN

• 1 RJ45 1 GbE LAN port

USB

• 2 USB 3.2 Gen1 Type-A ports(rear)
• 2 USB 2.0 Type-A ports(rear)
• 2 USB 3.2 Gen1 Type-A ports(front)
• 1 Thunderbolt™ 4 Type-C port(Rear)
• 1 USB 3.2 Gen2x2 Type-C port(Front)

Video

• 1 HDMI 2.1 port(Rear)
• 1 DisplayPort 2.1 port(Rear)
• 1 DisplayPort over USB Type-C port(Rear)

Audio

• 7.1 HD Audio
• Front Audio

System BIOSBIOS Type

• AMI 32MB SPI Flash

BIOS Features

• ACPI 6.0
• Plug and Play (PnP)
• Riser Card audio detection support
• SMBIOS 3.0 or later

SecurityHardware

• Trusted Platform Module (TPM) 2.0
• Silicon Root of Trust (RoT) – NIST 800-193 Compliant

Features

• Cryptographically Signed Firmware
• Secure Boot
• Secure Firmware Updates
• Automatic Firmware Recovery
• Supply Chain Security: Remote Attestation
• System Lockdown

PC Health MonitoringVoltage

• +1.0V PCH, +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, 5 (4-pin), CPU, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT, VRM Systems
  • Windows 11
  • View all OS Compatibility and Certification Matrix
  ChassisForm Factor
  • 17.72" (450 mm)
  Width
  • 8.07" (205 mm)
  Depth
  • 18.5" (470 mm)
  Package
  • 24.29" (H) x 12.8" (W) x 23.23" (D)
  Weight
  • Gross Weight: 30 lbs (13.61 kg)
  • Net Weight: 28 lbs (12.7 kg)
  Available Color
  • Black
  Front PanelButtons
  • Power On/Off
  LED
  • HDD activity
  • Power status LED
  Port
  • Audio Jack-Combo microphone input / audio output port
  • USB Type-A Ports-USB 3.2 Gen 1X1 ports (5G)
  • USB Type-C-USB 3.2 Gen 2X2 port (20G)
  Expansion SlotsPCI-Express (PCIe) Configuration
  • Default

    • 1 PCIe 5.0 x16 (in x16) FHFL slot
  • Option A

    • 1 PCIe 4.0 x4 LP slot
  • Option B

    • 1 PCIe 3.0 x1 LP slot
  • View AOC Options
  M.2
  • 1 M.2 PCIe 5.0 x4 NVMe slot (M-key 2280(default)/22110)
  • 1 M.2 PCIe 4.0 x4 NVMe slot (M-key 2280(default)/2260)
  Drive Bays / StorageDrive Bays Configuration
  • Option A: Total 4 bays
    • 2 internal fixed 2.5" SATA drive bays
    • 2 internal fixed 3.5" SATA drive bays
  • Option B: Total 4 bays
    • 4 internal fixed 2.5" SATA drive bays
  • View Drive Options
  M.2
  • 1 M.2 PCIe 5.0 x4 NVMe slot (M-key 2280(default); Capacity 1TB)
  • View M.2 Options
  System CoolingFans
  • Up to 3 Front 120mm Fan(s)
  • Up to 1 Rear 120mm Fan(s)
  • Up to 3 Top 120mm Fan(s) (optional)
  Power Supply1x 1000W Gold Level (90%) power supplyDimension (WxHxL)150 x 86 x 140 mmInput1000W: 100-240Vac / 47-63Hz+12VMax: 83.3A / Min: 0A (100Vac-240Vac)5V SBMax: 3A / Min: 0AOutput Type24pin ATXCertificationGold LevelOperating EnvironmentRoHS
  • RoHS Compliant
  Environmental Spec.
  • Operating Temperature: 10°C to 35°C (50°F to 95°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity: 8% to 90% (Non-Condensing)
  • Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
