Ports

24x 1G/10G SFP+ ports (LRM + MACsec)

2x 10G/25G/50G1 SFP ports

2x 10G/25G SFP ports (MACsec)

1x USB-C Console Port

1x RJ Console Port

1x OOBM port

1x USB Type A Host port

Power Supplies

2 field-replaceable, hotswappable power supply

slots 1 minimum power supply required (ordered separately)

Supported PSUs

JL085A

JL757A PSU

Fans

The switch has two fan tray slots and comes with two fan trays installed.

Min 2 fan trays required.

Fan trays are field replaceable and hotswappable.

Each fan tray contains two fans.

Mounting and Enclosure

Mounts in an EIA- standard 19 in. telco rack or equipment cabinet.

Horizontal surface mounting only. 2-post rack kit included.

Additional Specifications

CPU

Quad Core ARM Cortex™ A72 @ 1.8GHz

Memory and Flash

8 GB DDR4 32 GB eMMC

Packet Buffer

16 MB

Performance

System switching capacity

880 Gbps

System throughput capacity

660 Mpps

Model switching capacity

880 Gbps

Model throughput capacity

654 Mpps

Mounting and Enclosure

Mounts in an EIAstandard 19 in. telco rack or equipment cabinet. Horizontal surface mounting only. 2-post rack kit included.

Power supplies sold separately for the HPE Aruba 6300M series modular switches.
We ship all products according to manufacturer specifications. If the manufacturer does not include an option as standard with the product (power supply, fan tray etc) we do not either unless specifically stated. If you are have questions regarding what is included with a product, please contact us.
