ASUS Z8NA-D6 Server MotherboardIntroduction
Processor / System Bus
2 x Socket LGA1366
QPI 4.8 / 5.86 / 6.4 GT/s
Six-Core/Quad-Core Intel®Xeon®X5600/X5500 Series (95W)
Six-Core/Quad-Core/Dual Core Intel®Xeon®E5600/E5500 Series (80W)
Six-Core/Dual Core/Quad-Core Intel®Xeon®L5600/L5500 Series (60W/40W/38W)
Core Logic
Intel® 5500 IOH
Intel® ICH10R I/O Controller
Memory
Memory Size :
8GB, 16GB, 2GB, 1GB, 4GB RDIMM
1GB, 4GB, 2GB UDIMM
Capacity :Maximum up to 24GB UDIMM/Maximum up to 96GB RDIMM
Total Slots :6 (3-channel per CPU, 3 DIMM per CPU)
Memory Type :
RDIMM DDR3*
DDR3 UDIMM*
Expansion Slots
Slot Location 1 : PCI 32bit/33MHz
Slot Location 2 : MIO Slot for Audio card PCI-E x1 is not supported
Additional Slot 1 : PIKE Slot for Stroage expansion
Total Slot : 5
Slot Location 4 : PCI-E x8 (Gen2 X4 Link)
Slot Location 3 : PCI-E x8 (Gen2 X4 Link)
Slot Location 6 : PCI-E x16 (Gen2 X16 Link)
Storage
SAS/SATA Controller :
ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card(Optional)
ASUS PIKE 9230 4-port SATA 6G RAID card (Optional)
ASUS PIKE 2108-32PD 8-port SAS2 6G RAID card (Optional)
ASUS PIKE 2308 8-port SAS 6G RAID card (Optional)
ASUS PIKE 2208 8-port SAS 6G HW RAID card (Optional)
ASUS PIKE 2008 8-port SAS2 6G RAID card (Optional)
SATA Controller :
Intel® ICH10R
LSI® MegaRAID (For Linux/Windows)
(Support Software RAID 1, 0, 10 )
Intel® Matrix Storage (For Windows Only)
(Support Software RAID 1, 5, 0, 10 )
6 x SATA2 300MB/s
Networking
2 x Intel® 82574L
Graphic
Aspeed AST2050 with 8MB VRAM
Back I/O Ports
1 x External Serial Port
2 x External USB Port
1 x VGA Port
2 x RJ-45
1 x PS/2 KB/Mouse
Internal I/O Ports
1 x USB pin header , Up to 2 Devices
1 x Serial Port Header
2 x SMBus
2 x Front LAN LED
1 x Chassis Intruder
1 x Internal A Type USB Port
1 x Management Connector , Onboard socket for management card
1 x PSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector)*1
8 x Fan Header , 4pin
Management Solution
Software: ASWM2.0
Optional ASMB4-iKVM for KVM-over-Internet
Regulatory Compliance
CE, FCC(Class B), BSMI, C-Tick
Environment
Operation temperature: 10℃ ~ 35℃ / Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% (Non condensing)
Product SKUs
Standard Bulk Pack
Standard Gift Box Pack with ASMB4-iKVM
Standard Gift Box Pack
Standard Gift Box Pack with MIO
Standard Bulk Pack with ASMB4-iKVM
Monitoring
Fan RPM
CPU Temperature
Form Factor
ATX (12"x9.6", 305mm x 244mm)
Note
* Refer to ASUS Server AVL for latest update
*1:
Support Both ATX & SSI Power Supply
Minimum requiremen of ATX Power supply:
1)450W 2)All +12V output≧18A
