Conveniently operate a full build of RGB Core Single-Frame Fans using the 8-pin PWM and RGB combo headers.Fine-tune speeds for up to five PWM fans (including single-frame fan units), with Zero RPM mode for silent operation during low loads.Synchronize lighting effects on up to five NZXT RGB components to create a cohesive, system-wide look.Adjust fan speeds, personalize lighting, and create custom profiles via NZXT CAM software, which automatically detects each connected device.Secure the controller magnetically or use the included 3M™ Dual Lock™ Reclosable Fasteners.The included splitter cables have both 4-pin PWM and 4-pin RGB connectors, ensuring it works with any type of NZXT fan.Height 15.9 mm / 0.63 inWidth 70 mm / 2.76 inDepth 100 mm / 3.94 in
Output ChannelsFan3 x NZXT 8-pin (PWM only) / 1 x NZXT 8-pin (DC+PWM control) / 1 x 4-pin PWM (DC+PWM control)
RGB4 x NZXT 8-pin / 1 x NZXT RGB
Max LED SupportEach NZXT 8-pin channel supports up to 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to 5 NZXT devices.
Mounting OptionsMagnetic housing, 3M™ Dual Lock™ Reclosable Fasteners, or 2.5" SSD mounting screws
PSU Connector8-pin PCIe Power
Motherboard ConnectorInternal USB 2.0
