Key Features of RouterBOARD RB922UAGS-5HPacD:

• Wireless Standard: Supports 802.11ac with speeds up to 866 Mbps and channel widths of 20/40/80 MHz.
• Connectivity:
  • 1x SFP cage for fiber connections.
  • MiniPCIe slot with SIM support for 3G/4G modems or additional wireless cards.
  • USB port for external devices.
  • Gigabit Ethernet port for high-speed wired connections.
  • 2x MMCX connectors for the built-in 2x2 802.11ac radio.
• Operating System: Runs RouterOS L4 (AP license).
• Frequency Options:
  • RB922UAGS-5HPacD-US (USA): Factory-locked to 5170-5250 MHz and 5725-5835 MHz (International): Supports 5150-5875 MHz (may vary by country regulations).

A versatile router ideal for custom wireless solutions.

Key Specifications for RouterBOARD RB922UAGS-5HPacD:

Product Details:

• Model: RB922UAGS-5HPacD
• Architecture: MIPSBE
• CPU: QCA9557, 720 MHz, single-core
• RAM: 128 MB
• Storage: 128 MB NAND
• RouterOS License: Level 4
• Operating Temperature: -40°C to 70°C
• MTBF: ~100,000 hours at 25°C
• Dimensions: 105 x 105 2 (DC Jack, Passive PoE)
• Voltage Range: 8-30 V
• Max Power Consumption: 17 W
• Cooling: Passive

Wireless (5 GHz):

• Max Data Rate: 867 Mbps
• Standards: 802.11a/n/ac (Wi-Fi 5)
• Chains: 2
• Chip Model: QCA9882
• Transmit Power: Up to 31 dBm
• Receive Sensitivity: Down to -96 dBm

Network Interfaces:

• Ethernet: 1x Gigabit Ethernet
• Fiber: 1x SFP (DDMI Slot: 1 (with SIM support for 3G/4G modems)
• USB Port: 1x USB Type-A (max current 1A, power reset supported)

Additional Features:

• PCB and Voltage Monitors, Beeper

Certifications: CE, FCC, IC, EAC, ROHS

Ideal for high-performance custom wireless deployments.
