Model
SPATIUM M470 PCIe 4.0 NVMe M.2
P/N
S78-440L420-P83
Overview
MSI SPATIUM M470 PCIe 4.0 NVMe M.2
Charging Ahead with Speed
From the MSI universe comes storage with blazing speeds andincredible performance. Take your system to the next level with SPATIUM.
A Need for Speed!
Optimized for the PCIe Gen4 interface, SPATIUM M470 SSDreaches read/write speeds up to 5000/4400 MB/s, allowing for rapid datatransfer and shortened game load times.
Small Size, More Storage
The latest 3D NAND flash technology brings dense storage ina compact design and allows SPATIUM storage capacities up to 2TB.
* Refer to specifications for actual capacity.
Don't Stop Gaming
Built-in data security and error-correction capabilitiesextend the endurance and longevity of the NAND flash storage.
Take Care of Your Data
Migrate your data, monitor drive health and performancemetrics in real-time with MSI Center. Prevent loss of data using the providedActiphy software solution which includes backup & restore functionality.
Capacity
1TB
Controller
PHISON E16
Flash Memory
3D NAND
DRAM Cache
1GB DDR4
Form Factor
M.2 2280
Interface
PCIe Gen4 x4, NVMe 1.3
Compatibility
PCIe Gen4 / Gen3 / Gen2 / Gen1
Dimensions
80.00mm (L) x 22.00mm (W) x 2.15mm (H)
Weight
0.008kg
Sequential Read
Up to 5,000 MB/s
Sequential Write
Up to 4,400 MB/s
Random Read 4KB
Up to 600K IOPS
Random Write 4KB
Up to 600K IOPS
Maximum Operating Power
6.3W
Idle Power PS3
20 mW
Low Power L1.2
2 mW
Operating Temperature
0°C – 70°C
Storage Temperature
-40°C – 85°C
Terabytes Written (TBW)
1600
Mean Time Between Failure (MTBF)
Up to 1,700,000 Hours
Advanced Features
TRIM (Performance Optimization, OS support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
TCG OPAL2.0/Pyrite (Encryption, Data Security)
