Specification
- Compliant with PCI Express Specification Revision v2.1
- Supports 1-Lane 2.5/5Gbps PCI Express bus
- Onboard single 2.5G network port, integrated 10/100/1000M/2.5G transceiver
- Support 2.5G and 1G Lite, 100M mode
- Auto-negotiation with extended next page functionality
- Support for swap/sex/skew correction
- Cross detection and automatic correction
- Compatible with IEEE802.3, IEEE802.3u, IEEE802.3ab
- Support IEEE1588v1, IEEE1588v2, IEEE80.2AS time synchronization
- Support shaping algorithm based on IEEE802.1Qav credit
- Support IEEE802.1P layer 2 priority encoding
- Support IEEE802.1Q VLAN tagging
- Support IEEE802.3az-2010
- Support IEEE802.3bz-2016 (NGBASET)
- Support full duplex flow control (IEEE802.3x)
- Supports jumbo frames up to 16K bytes
- Support for Virtual Machine Queue (VMQ)
- Support quad-core receive-side scaling (RSS)


Bus type: MiniPCIE
Transmission medium: 1 x 2.5G RJ45 port
Transmission rate: 2.5G/1000/100Mbps
Network Mode: Support 2.5G and 1G Lite mode
Network topology: - Support IEEE1588v1, IEEE1588v2, IEEE80.2AS time synchronization
- Support shaping algorithm based on IEEE802.1Qav credit
- Support IEEE802.1P layer 2 priority encoding
- Support IEEE802.1Q VLAN tagging
- Support IEEE802.3az-2010
- Support IEEE802.3bz-2016 (NGBASET)
- Support full duplex flow control (IEEE802.3x)

Features: - Auto-negotiation with extended next page functionality
- Support for swap/sex/skew correction
- Cross detection and automatic correction
- Support hardware ECC (Error Correction Code), hardware CRC (Cyclic Redundancy Check) function
- Supports PCI MSI (Message Signaled Interrupt) and MSI-X
- Supports ECMA-393 ProxZzzy standard for sleeping hosts
- Supports Wake-on-LAN and "RealWow!" technology (remote wake-up)

System Requirements:
- Win 7/Win 8/Server 2008/Win 8.1/Server 2012/2016, Win 10 32/64bit, Linux...
- One available MiniPCIE slot
