M12 to RJ45 Industrial Ethernet Cable — Cat6A S/FTP Double Shielded, IP67 Waterproof, A/D/X-Coded 4/8-Pin,
High-Flex Drag Chain Cable for PLC, Servo, Robotic Arm & Industrial Camera

Built for the factory floor, not the office. This M12-to-RJ45 industrial Ethernet cable combines a
threaded M12 connector with a standard RJ45 plug, so you can link industrial equipment — PLC, servo
drives, robotic arms, machine vision cameras, sensors and control cabinets — straight into a normal
switch or control-room network. Double-layer shielding (aluminium foil + tinned copper braid) and a
7.0mm flame-retardant PVC jacket keep the signal clean and the cable alive in the harshest conditions:
IP67 waterproof, oil resistant, and rated from -40°C to +105°C. Verified by FLUKE testing and proven
over 2,000,000+ drag-chain motion cycles, it is the cable you install once and forget about.

Key Features:

• IP67 Waterproof Rating — sealed M12 threaded coupling resists water, dust, shock and vibration;
  stable high-speed transmission even in wet, oily or outdoor industrial environments.
• Double-Layer Shielding (S/FTP) — aluminium foil plus high-density tinned-copper braided mesh blocks
  electromagnetic interference and crosstalk, so the line stays stable with no dropped communication.
• High-Flex Drag Chain Design — 2,000,000+ drag-chain motion cycles tested; anti-sway, superb bending
  resistance for continuously moving axes, cable carriers and robotic arms.
• Tinned Oxygen-Free Copper Core, 26AWG — 99.99% pure multi-strand copper with low resistance for fast,
  loss-free data transmission; supports PoE / PoE+ power supply.
• Gold-Plated Contacts + Shielded Metal Shell — trident gold-plated contact points bite tightly into the
  core for reliable conductivity; the metal housing resists oxidation and repeated plugging.
• Integrated Injection Molding — one-piece molded joint and a high-resilience net tail that is anti-slip,
  wear-resistant and far more durable against bending than a screw-together plug.
• Wide Temperature Range, -40°C to +105°C — works normally in cold storage, outdoor cabinets and
  machine-side heat, where ordinary patch cords harden or crack.
• Flame Retardant Jacket — special high-temperature flame-retardant cover releases white smoke and
  self-extinguishes immediately once the flame source is removed.
• FLUKE Tested — factory Cat6A permanent-link test passed (F/UTP, T568B), supporting 1000BASE-TX,
  2.5G/5G/10GBASE-T; meets CE / ISO9001 quality requirements.

Specifications:

• Name: M12 to RJ45 Industrial Ethernet Cable
• Interface: M12 A-Code / D-Code / X-Code, 4-Pin or 8-Pin, male - to - RJ45 male
• Standard: Cat6A, T568B wiring
• Shielding: Double layer — aluminium foil + tinned copper braided mesh (S/FTP)
• Core Material: 26AWG tinned oxygen-free copper, multi-strand
• Plug: Gold-plated contact points, shielded metal shell
• Exterior: PVC, flame retardant, integrated injection molding
• Work Environment: -40°C ~ +105°C
• Cable Diameter: 7.0mm
• IP Rating: IP67
• Connector Size: RJ45 plug 42mm long x 12mm wide; M12 connector 45mm long x 13mm wide
• Length: multiple standard lengths available, custom lengths on request
• Color: Green
• Product Features: high flexibility, bending resistance, double shielding, anti-interference,
  tensile resistance, PoE power supply support

How to Choose the M12 Code (very important - please read before ordering):

M12 connectors are keyed by code and NOT interchangeable. Tell us which code and pin count you need:

• A-Code (8-Pin) — standard sensor/actuator code, the most common industrial Ethernet choice.
• D-Code (4-Pin) — 100 Mbps / Gigabit Ethernet, widely used on Profinet and EtherCAT devices.
• X-Code (8-Pin) — 8-pin coding for 10 Gbps / Cat6A industrial Ethernet, the highest performance option.
  Wiring diagrams (T568B) for M12 D-Code 4-Pin, M12 A-Code 8-Pin and M12 X-Code 8-Pin to RJ45 are available
  in the images; message us if you are unsure — send us the model of your device and we will confirm the
  correct version for you.

Applications:

• Industrial automation — PLC, servo motors/drives, robotic arms, machine tools, assembly lines
• Machine vision & imaging — industrial cameras, inspection systems, sensor networks
• Control cabinets and switches — patch leads from M12 outlet to RJ45 switch port or patch panel
• Industrial fieldbus / Real-time Ethernet — Profinet, EtherCAT, EtherNet/IP style machine networks,
  where shielded cabling is required
• Outdoor, wet and oily environments — outdoor cabinets, food & beverage lines, cold storage, wash-down areas
• Automated equipment — automated guided vehicles, UAV/drone ground equipment, testing instruments,
  new energy vehicle production lines
• General networking where ruggedness matters — routers, ADSL modems, computers and set-top boxes

Package Includes:

1 x M12 to RJ45 Industrial Ethernet Cable, green, M12 male to RJ45 male
(code, pin count and length as selected)

Why Buy From Us:

BYXGD is a professional factory-direct brand of industrial network cabling and fiber optic tools. Every
industrial cable is produced under an ISO9001 quality system and verified with FLUKE instruments and
CE testing, so the performance you receive is standardized and repeatable — not guesswork. Factory
direct pricing, custom lengths and mixed-code orders are all welcome. Not sure about the M12 code,
pin count, or wiring for your machine? Send us a message with your equipment model and we will confirm
the right cable before you buy.
