Litz Wire 120/38 Coil Crystal Radio Loop Antenna AWG38 X 120 Strands

If you need other lengths, please send a message to contact us!

Litz wire multi strands wire strands silk bag making

Specifications：0.1mm X 120 shares. AWG38 X 120 Strands

Copper core cross-sectional area of about 0.9425 square mm. The total external diameter is about 1.39 mm.

This product is made of polyurethane enameled wire for wire polyester wire,
with good direct welding property, solder temperature of 375 C + 5 degrees. Temperature resistance: 155.

Applicable to the manufacture of all kinds of electronic instruments,
instruments in the original inductance and other occasions. Good performance of high frequency electric.

(Note: the data for micrometer manual measurement, there may be some errors, for reference only!)

Litz wire is a special type of wire used in electronics.
The wire is designed to reduce the skin effect and proximity effect losses in conductors.
it consists of many thin wires and individually coated with an insulating film and twisted or woven together,
following a carefully prescribed pattern often involving several levels
(groups of twisted wires are twisted together, etc.).
