Intel DBS2400EP4 Server Board, SSI CEB, Socket B2, DDR3
Essentials
Status: Launched
Launch Date: Q2'12
# of QPI Links: 1
Board Form Factor: SSI CEB 12" x 10.5"
Chassis Form Factor: Rack
Socket: Socket B2
Integrated Systems Available: Yes
Integrated BMC with IPMI: IPMI 2.0
Rack-Friendly Board: Yes
Embedded Options Available: Yes
Max TDP: 95 W
Included Items: (1)General Purpose Intel® Server Board S2400EP4, On Select SKUs: (2) SATA cables, (1) DVD contains Intel® Multi-Server Manager Software and Intel Deployment Assistant, (1) Quick Configuration Label
Description: Intel® Server Board S2400EP4 is an entry rack optimized server board supporting two Intel® Xeon E5-2400 CPUs, 8 DIMMs, Quad NICs, external I/O module and internal ROC module
Target Market: Embedded
Memory Specifications
Max Memory Size (dependent on memory type): 128 GB
Memory Types: DDR3 ECC UDIMM/LV 1333 1600, RDIMM 1066, RDIMM/LV 1333 1600
# of Memory Channels: 6
Max Memory Bandwidth: 614.4 GB/s
Physical Address Extensions: 46-bit
# of DIMMs: 8
ECC Memory Supported ‡: Yes
Graphics Specifications
Integrated Graphics ‡: Yes
Graphics Output: D-sub
Intel® Clear Video Technology: No
Discrete Graphics: Supported
Expansion Options
PCI Express Revision: 3
PCIe x4 Gen 3: 0
PCIe x8 Gen 3: 0
PCIe x16 Gen 3: 1
IO Expansion x8 Gen 2.x: 1
Connector for Intel® I/O Expansion Module: 1
I/O Specifications
USB Revision: USB 2.0
# of USB Ports: 4
USB 2.0 Configuration (Back + Internal): 7
Total # of SATA Ports: 2
RAID Configuration: SW Raid 0/1/10/5 (LSI + RSTE)
# of Serial Ports: 1
# of LAN Ports: 4
Integrated LAN: 4x 1GbE
Embedded USB (eUSB) Solid State Drive Option: No
Integrated SAS Ports: 0
Integrated InfiniBand*: No
Package Specifications
Max CPU Configuration: 2
Low Halogen Options Available: See MDDS
Advanced Technologies
Intel® Virtualization Technology for Directed I/O (VT-d) ‡: Yes
Intel® Trusted Execution Technology ‡: Yes
AES New Instructions: Yes
Intel® Remote Management Module Support: Yes
Intel® Node Manager: Yes
TPM: Yes
TPM Version: 1.2
Intel® Matrix Storage Technology: Yes
Intel® Fast Memory Access: Yes
Intel® Flex Memory Access: Yes
Intel® I/O Acceleration Technology: Yes
Intel® Advanced Management Technology: Yes
Intel® Efficient Power Technology: Yes
Intel® Quiet Thermal Technology: Yes
