IOGEAR's exclusive WiFi technology employs detachable antenna, which can be finely-tuned for exceptional horizontal or vertical signals up to twice the range of traditional Wi-Fi Access Points. This delivers the perfect solution for multi-story homes and office. No more dropped connections or dead zones.

Wirelessly share an Internet connection with multiple computers

Wi-Fi Technology

- Detachable antenna beams stronger signal for specific areas, great for upstairs/ downstairs; focused signal keeps out unwanted access

Simple, easy-to-use setup has you running in minutes

Turnkey firewall and wireless security packages keep you safe from hackers

Built-in 10/100 Base T Ethernet switch allows you to network up to four additional computers

Can be positioned upright or flat for maximum utility

Elegant finish, complements any desktop

FunctionGWA504Operating Temperature0 ~ 50°CStorage Temperature-20~65°COperating System SupportWindows 98SE/ME/2000/NT 4.0/XPTransfer Rate54,48,36,24,18,12,11,6,5.5,2,1Mbps, auto-fallbackHumidity10% - 90% non-condensingNetwork ProtocolTCP/IPConnectors (Input)one ethernet port for WANConnectors (Output)four ethernet ports for LANLEDs10/100 Mbps4WAN1WLAN1Transmission Power21 dBm (maximum)Frequency Band2.400 ~ 2.4835 GHzModulationCCK, BPSK, QPSK, 16-QAM, 64-QAMData Rate10/100 MbpsSensitivity-68~-85 dBm(typical)SecuritySupport WPA, WEP (64,128bit), AESStandardsIEEE 802.11g and 802.11bOperating RangeOpen Space: 11Mbps >200m, 54Mbps > 50mNumber of Channel11RF SpreadingOFDM, DSSSAntenna Typedetachable antennaPower DimensionsWidth19.5 in.Height9 in.Depth4 in.Unit Package DimensionsWidth10.5 in. (26.7 cm.)Height9 in. (22.5 cm.)Depth3.85 in. (10 cm.)Master CartonWidth17.9 in. (45.6 cm.)Height10.7 in. (27.2 cm.)Depth23.8 in. (60.5 cm)Master Carton Qty.12WeightMaster Carton Wt.34.58 lbs. (15.72 Kg.)Unit Pack Wt.2.25 lbs.Unit Wt.0.85 lbs. (0.38 kg.)
