CPU

Supports Intel 45nm Core 2 Quad(Yorkfield) and Core2 Duo(Wolfdale) series processors. (please refer to the CPU support list for more detail)

LGA775 socket for latest Intel® Core 2 Quad(95W) / Core 2 Duo / Pentium Dual-Core (E21XX) / Celeron 4XX series processor

FSB 1333/1066/800 MHz

CHIPSET

Intel® G33 & ICH9

North Bridge: Intel® G33

South Bridge: Intel® ICH9

GRAPHICS

Integrated Intel® Graphics Media Accelerator 3100 (GMA3100)

Max Dynamic Video Memory : 287MB (Vista) / 384MB (XP)

MEMORY

Dual-channel DDR2 memory architecture

4 x 240-pin DDR2 DIMM socket support up to 8 GB

Support DDR2 800/667 DDR SDRAM

EXPANSION SLOT

1 x PCI Express x16 slot

1 x PCI Express x1 slot

2 x PCI slots

STORAGE

Support by Intel® ICH9

4 x Serial ATA 3.0Gb/s devices

AUDIO

Realtek ALC883 support 8-ch HD Audio

LAN

Realtek GigaLAN 8111B (Realtek 10/100 LAN 8101E optional)

REAR PANEL I/O

1 x PS/2 keyboard & PS/2 mouse connectors

4 x USB ports

1 x VGA port

1 x Serial port (COM1)

1 x Parallel port (LPT1) (Optional)

1 x 1394a port(optional)

1 x RJ45 LAN connector

1 x Audio port

INTERNAL I/O CONNECTORS & HEADERS

1 x 24-pin ATX Power Supply connector

1 x 4-pin ATX 12V connector

1 x FDD connector supports one 360K~2.88MB FDD

4 x Serial ATA connectors

1 x COM2 header (optional)

4 x USB 2.0 headers support additional 8 USB ports

1 x 1394a header(optional)

1 x Clear CMOS header

1 x Front panel header

1 x Front panel audio header

1 x CD in header

CPUFAN/SYSFAN connectors

SYSTEM BIOS

AMI BIOS with 8Mb SPI ROM

Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI

Supports ACPI revision 1.0 specification
