CPU Support

Intel

CPU Socket

LGA 2066/2011 (Narrow Type, 56mm x 94mm Mounting Pitch)

Screw Type

M4

Installation Torque

10-16 in-lb

Solution

1U Server

Dimensions

103.0 x 78.0 x 28.0 mm

Weight

470 g

Material

Copper Heatsink with Skiving Fins

Fan Dimension

80 x 80 x 15 mm

Speed

At Duty Cycle 20%: 1000 RPM
At Duty Cycle 50%: 3500 RPM
At Duty Cycle 100%: 7000 RPM

Bearing

2 Ball Bearing

Rated Voltage

12V

Power

At Duty Cycle 20%: 0.6 W
At Duty Cycle 50%: 3.84 W
At Duty Cycle 100%: 19.2 W

Air Flow

At Duty Cycle 20%: 6.5 CFM
At Duty Cycle 50%: 11.2 CFM
At Duty Cycle 100%: 22.28 CFM

Noise Level

At Duty Cycle 20%: 21.5 dBA
At Duty Cycle 50%: 43.0 dBA
At Duty Cycle 100%: 59.14 dBA

Air Pressure

At Duty Cycle 20%: 2.27 mm-H2O
At Duty Cycle 50%: 18.56 mm-H2O
At Duty Cycle 100%: 74.18 mm-H2O

Life- Continuous operating

under normal temperature

(40°C/104 °F)

70,000 Hours
