Item Description

CPU Support

Intel

CPU Socket

LGA 115X/1200

Screw Type

M3

Installation Torque

5-7 in-lb

Solution

1U Server

Dimensions

85.0 x 81.5 x 28.5 mm

Weight

355g ± 5g

Material

Copper Heatsink with Skiving Fins

Fan Dimension

Ø80.0 x 15.0 mm

Speed

At Duty Cycle 20%: 1200 RPM
At Duty Cycle 50%: 2600 RPM
At Duty Cycle 100%: 5000 RPM

Bearing

2 Ball Bearing

Rated Voltage

12V

Power

At Duty Cycle 20%: 0.60 W
At Duty Cycle 50%: 1.44 W
At Duty Cycle 100%: 9.60 W

Air Flow

At Duty Cycle 20%: 3.533 CFM
At Duty Cycle 50%: 7.645 CFM
At Duty Cycle 100%: 14.719 CFM

Noise Level

At Duty Cycle 20%: 20.71 dBA
At Duty Cycle 50%: 37.5 dBA
At Duty Cycle 100%: 51.7 dBA

Static Pressure

At Duty Cycle 20%: 2.083 mm-H2O
At Duty Cycle 50%: 9.780 mm-H2O
At Duty Cycle 100%: 36.168 mm-H2O

Lead Wire Pin Out

Pin1-Black (-)
Pin2-Yellow (+)
Pin3-Green (Techometer/Signal output)
Pin4-Blue (PWM)

Life – Continuous operating

under normal temperature

(40 °C or 104 °F)

70,000 Hours
