WAVLINK · DISPLAYLINK SERIES Two Ways to Add
More Screens. Both run on DisplayLink — the technology that breaks the native multi-display limit on M1 / M2 / M3 Macs.
Pick dual HDMI for simplicity, or dual HDMI + dual DisplayPort for the full resolution toolkit. DISPLAYLINK DUAL 4K@60Hzfor M1 / M2 / M3 MAC READYNO POWER ADAPTER NEEDED2×HDMIUG6902H PORTS4096×2160@60Hz DUAL5120×14405K ON DP6MAX SCREENS (WIN)📊 Side-by-Side SpecificationsPorts, resolutions, materials and compatibility — compared at a glanceFeature2 × HDMI2 × HDMI + 2 × DPVideo Outputs2 × HDMI2 × HDMI + 2 × DisplayPortSingle DisplayHDMI1 / HDMI2 — 4096×2160 @ 60HzDP — 4096×2160 @ 60Hz / 5120×1440 @ 60Hz
HDMI — 4096×2160 @ 60HzDual DisplayHDMI1 + HDMI2 — 2 × 4096×2160 @ 60Hz DP + DP — 2 × 5120×1440@60Hz or 2 × 4096×2160@60Hz or 4096×2160@60Hz + 5120×1440@60Hz
DP + HDMI — 2 × 4096×2160@60Hz or 5120×1440@60Hz + 4096×2160@60Hz
HDMI + HDMI — 2 × 4096×2160 @ 60Hz Host ConnectionUSB-A + USB-A to C converter · TB 4/3 and USB 4 compatibleHybrid 2-in-1 cable — USB-C / USB-A / Thunderbolt 3/4 / USB 4USB SpeedUSB 3.1 up to 5 Gbps · backwards compatible with USB 2.0USB 3.0 host connectionHousing MaterialABS Plastic + PVC CableAluminum Alloy + PVC CableColorBlackSilver/BlackUnit Size10.0 × 5.0 × 1.5 cm / 3.9 × 2.0 × 0.6 in11.4 × 7.3 × 1.5 cm / 4.5 × 2.9 × 0.6 inCable Length12cm / 4.7in9cm / 3.5inItem Weight90g / 3.2oz137g / 4.8ozMax ScreensAdd multiple adapters — up to 6 extra displays on Windows, 4 on Mac OSSame DisplayLink multi-adapter capabilitySystem RequirementWindows 7/8/8.1/10/11 · MacOS 10.14–13.x or later · Chrome OS · Android · Ubuntu · HarmonyOSWindows 7/8/8.1/10/11 · MacOS 10.14–13.x or later · Chrome OS · Android · Ubuntu · HarmonyOSExternal PowerNot requiredNot required Driver installation is required — plug and play is not supported. For Mac users, grant DisplayLink Manager permission to record your screen. DUAL HDMI · 90g · BLACK2x HDMI DisplayLink · Dual 4K@60Hz · 4096×2160 max · 90g / 3.2oz · No power adapterThe UG6902H display adapter incorporates the advanced DisplayLink technology, allowing you to output video through dual HDMI ports. This hub features two HDMI ports, enabling dual display functionality with a maximum resolution of 4096×2160 @ 60Hz. Comes with a USB-A port and a USB-A to C converter, this adapter is compatible with Thunderbolt 4/3 ports and USB 4 ports found on compatible computers.🖥️ Dual Displays — Crystal-Clear Visual FeastThe USB 3.1 video adapter adds support for two HDMI monitors, capable of both extending or mirroring displays with resolutions up to dual 4096×2160 @ 60Hz. Enjoy high-quality visuals and enhanced productivity across multiple monitors.🔄 Multi Display ModesMirror / extend / rotation / clamshell modes for choosing, to easily meet your different needs. You can use it on many occasions such as office, meeting or home theater.➕ Expand Your WorkspaceMultiple USB adapters can be added to your PC for connecting up to 6 additional displays on Windows and 4 on Mac OS.🎒 Portable DesignLightweight at 90g / 3.2oz, compact and portable size — handy for business trips, meetings, switching work at home or office, etc.🔌 Inputs for ChooseComes with a hybrid 2-in-1 cable, it is easy to connect a USB-enabled device such as laptop, desktop, tablet or phone for a multi-monitor solution.⚡ Super Speed & 4K Without LimitationTake advantage of the super-speed USB 3.1 up to 5 Gbps to quickly transfer files — ensuring stable transmission and reduced latency. USB 3.1 is backwards compatible with USB 2.0, and 4096×2160 @ 60Hz resolution remains when connecting to a USB 2.0 interface.🖥️ Multiple Display Resolution (Max.)Single Display:
HDMI1 / HDMI2 — 4096×2160 @ 60HzDual Display:
HDMI1 + HDMI2 — 2 × 4096×2160 @ 60Hz 🔧 SPECIFICATION • Model: WL-UG6902H
• Color: Black
• Ports: 2 × 4K@60Hz HDMI (backward compatible with lower resolutions)
• Unit Size: 10.0 × 5.0 × 1.5 cm / 3.9 × 2.0 × 0.6 in (L × W × H)
• Material Type: ABS Plastic + PVC Cable
• Item Weight: 90g / 3.2oz
• Cable Length: 12cm / 4.7in
• System Requirement: Windows 7/8/8.1/10/11 · MacOS 10.14–13.x or later · Chrome OS · Android · Ubuntu · HarmonyOS 💡 WARM TIPS 1. Do not support Linux, Unix, iOS and iPad OS.
2. Driver installation is required — do not support plug and play. Please visit the website to download the latest driver.
3. No additional power source is required for this adapter — work clutter-free with fewer power cords around the desk.
4. Android devices support mirror mode ONLY with resolution up to 1080P.
5. Windows / Mac 12.x based devices support rotation and clamshell modes.
6. Does not support playback of HDCP copyright-protected content from Blu-ray / Netflix / Prime / iTunes / Hulu and other platforms.
7. Suitable for office work, handling spreadsheets, documents or browsing the web. Not suitable for gaming or other high-intensity tasks.
8. For Mac users, it is necessary to grant permission to the DisplayLink Manager to record your screen. 📦 PACKAGE INCLUDES • 1 × USB 3.1 to HDMI Dual Display Adapter
• 1 × CD-Shaped Card for Driver Download Links
• 1 × Quick Start Guide ❓ Q & AQ1: Will this work with my MacBook on 2 monitors showing different screens?
A1: Yes, it supports extending two different screens for Mac OS. Q2: Will it have audio if I'm using this adapter?
A2: Yes, it supports audio if there is a built-in speaker with your monitor. 2 × HDMI + 2 × DP · ALUMINUM · SILVER2x HDMI+2x DP(Silver/Black)DisplayLink · Dual 4K/5K · 5120×1440 max on DP · Aluminum Alloy · for MacBook NeoEquipped with dual DisplayPort and HDMI ports to experience the convenience of a dual-monitor setup, accomplished through a single USB 3.0 connection to your host device. Supporting resolutions of up to dual 4096×2160@60Hz / 5120×1440@60Hz — only the DP port supports 5K resolution, while HDMI ports support max 4K resolution.🍎 Perfect for MacBook Neo Multi-Monitor SetupFully optimized for the latest MacBook Neo. While the native system may limit external displays, our DisplayLink-powered UG69DH2 breaks the boundary, allowing you to extend dual 4K monitors seamlessly. As recommended by AppleInsider, it's the ultimate productivity solution for the new MacBook Neo era.🏢 Enterprise-class ManageabilityWAVLINK's DL-chip docks enhance efficiency and productivity in corporate environments with advanced features. They offer enterprise-class manageability, enabling seamless operations in high-performance workspaces. Tailored to meet the needs of enterprise customers, the DL series docking stations optimize productivity for essential tasks.🖥️ Multi-task Dual 4K / 5K DisplayYou can enjoy crisp and clear visuals on both monitors. The dual monitor adapter is an excellent choice for work-related tasks such as web browsing, spreadsheet preparation and word processing. However, it's important to note that the adapter may not be suitable for gaming or graphics-intensive work, and it does not support the playback of HDCP-protected content.🔌 Hybrid 2-in-1 CableThe external graphic card is equipped with a hybrid 2-in-1 cable, allowing for easy connectivity to a variety of devices. It can be connected to USB-C, USB-A, Thunderbolt 3/4 and USB 4 ports, providing versatility and compatibility with different devices. Once connected, you can effortlessly mirror or extend your screen content, greatly enhancing your work efficiency.🖥️ Multiple Display Resolution (Max.)Single Display:
DP — 4096×2160 @ 60Hz / 5120×1440 @ 60Hz
HDMI — 4096×2160 @ 60HzDual Display:
DP + DP — 2 × 5120×1440@60Hz or 2 × 4096×2160@60Hz or 4096×2160@60Hz + 5120×1440@60Hz
DP + HDMI — 2 × 4096×2160@60Hz or 5120×1440@60Hz + 4096×2160@60Hz
HDMI + HDMI — 2 × 4096×2160 @ 60Hz 🔧 SPECIFICATION • Model: WL-UG69DH2
• Color: Silver
• Ports: 2 × 4K@60Hz HDMI + 2 × 4K/5K@60Hz DisplayPort
• Unit Size: 11.4 × 7.3 × 1.5 cm / 4.5 × 2.9 × 0.6 in (L × W × H)
• Material Type: Aluminum Alloy + PVC Cable
• Item Weight: 137g / 4.8oz
• Cable Length: 9cm / 3.5in
• System Requirement: Windows 7/8/8.1/10/11 · MacOS 10.14–13.x or later · Chrome OS · Android · Ubuntu · HarmonyOS 💡 WARM TIPS 1. Do not support Linux, Unix, iOS and iPad OS.
2. Driver installation is required — do not support plug and play. Please visit the website to download the latest driver.
3. No additional power source is required for this adapter — work clutter-free with fewer power cords around the desk.
4. Android devices support mirror mode ONLY with resolution up to 1080P.
5. Windows / Mac 12.x based devices support rotation and clamshell modes.
6. The DP and HDMI in the same video stream CANNOT be used simultaneously.
7. Does not support playback of HDCP copyright-protected content from Blu-ray / Netflix / Prime / iTunes / Hulu and other platforms.
8. Suitable for office work, handling spreadsheets, documents or browsing the web. Not suitable for gaming or other high-intensity tasks.
9. For Mac users, it is necessary to grant permission to the DisplayLink Manager to record your screen.
10. Only DP ports support 5K (5120×1440) @ 60Hz resolution, while HDMI ports can achieve a maximum of 4K resolution. 📦 WHAT YOU GET • 1 × USB 3.0 to DisplayPort / HDMI Dual Display Adapter (cable length: 90mm / 3.5in)
• 1 × CD-Shaped Card for Driver Download Links
• 1 × Quick Start Guide
1-Year worry-free warranty (extra 6 months for registered members) plus life-long friendly customer service and technical support.❓ Q & AQ1: Will this work with my MacBook on 2 monitors showing different screens?
A1: Yes, it supports extending two different screens for Mac OS. Q2: Will it have audio if I'm using this adapter?
A2: Yes, it supports audio if there is a built-in speaker with your monitor. Which Adapter Fits Your Desk?Choose the (2 × HDMI) if…
You want the simplest dual-screen upgrade in the lightest body — 90g, 12cm cable, dual HDMI only, and Thunderbolt 4/3 / USB 4 host compatibility. Ideal for MacBooks, tablets and travel desks. Choose the (2 × HDMI + 2 × DP) if…
You need the full multi-monitor toolkit — 4 video ports, 5K 5120×1440 on DP, aluminum durability, and the flexibility to mix HDMI and DisplayPort monitors. The enterprise-grade pick for heavy desk setups and MacBook Neo workflows. USE THE DROPDOWN ABOVE TO SELECT YOUR MODELWAVLINKDISPLAYLINK · DUAL 4K / 5K · M1/M2/M3 MAC · USB-C / USB-A
