2x Gigabit SFP

IOS-XE 16.12

ipbasek9

2x PWR-C1-1100WAC(Takes C15 Plug)

Minor signs of prior use, including scratches
scuffs and possible adhesive residue remaining.

Power Cord(s)

Switch#show env all
Switch 1 FAN 1 is OK
Switch 1 FAN 2 is OK
Switch 1 FAN 3 is OK
FAN PS-1 is OK
FAN PS-2 is OK
Switch 1: SYSTEM TEMPERATURE is OK
Inlet Temperature Value: 27 Degree Celsius
Temperature State: GREEN
Yellow Threshold : 46 Degree Celsius
Red Threshold : 56 Degree CelsiusHotspot Temperature Value: 40 Degree Celsius
Temperature State: GREEN
Yellow Threshold : 105 Degree Celsius
Red Threshold : 125 Degree Celsius
SW PID Serial# Status Sys Pwr PoE Pwr Watts
-- ------------------ ---------- --------------- ------- ------- -----
1A PWR-C1-1100WAC LIT17350DQA OK Good Good 1100
1B PWR-C1-1100WAC LIT183112D8 OK Good Good 1100Switch#show inv
NAME: "c38xx Stack", DESCR: "c38xx Stack"
PID: WS-C3850-48P-S , VID: V07 , SN: FOC2225L0AJNAME: "Switch 1", DESCR: "WS-C3850-48P-S"
PID: WS-C3850-48P-S , VID: V07 , SN: FOC2225L0AJNAME: "Switch 1 - Power Supply A", DESCR: "Switch 1 - Power Supply A"
PID: PWR-C1-1100WAC , VID: V01 , SN: LIT17350DQANAME: "Switch 1 - Power Supply B", DESCR: "Switch 1 - Power Supply B"
PID: PWR-C1-1100WAC , VID: V01 , SN: LIT183112D8NAME: "Switch 1 FRU Uplink Module 1", DESCR: "2x1G 2x10G Uplink Module"
PID: C3850-NM-2-10G , VID: V01 , SN: FOC221320M7
Switch#show post
Stored system POST messages:Switch 1
---------POST: MBIST Tests : Begin
POST: MBIST Tests : End, Status PassedPOST: CRYPTO Tests : Begin
POST: CRYPTO Tests : End, Status PassedPOST: PHY Loopback: loopback Test : Begin
POST: PHY Loopback: loopback Test : End, Status PassedPOST: Inline Power Controller Tests : Begin
POST: Inline Power Controller Tests : End, Status PassedPOST: Thermal, Temperature Tests : Begin
POST: Thermal, Temperature Tests : End, Status PassedPOST: Thermal, Fan Tests : Begin
POST: Thermal, Fan Tests : End, Status PassedPOST: SIF Tests : Begin
POST: SIF Tests : End, Status Passed
Switch#show int statusPort Name Status Vlan Duplex Speed Type
Gi1/0/1 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/2 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/3 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/4 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/5 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/6 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/7 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/8 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/9 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/10 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/11 notconnect 1 auto auto 10/100/1000BaseTXPort Name Status Vlan Duplex Speed Type
Gi1/0/12 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/13 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/14 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/15 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/16 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/17 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/18 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/19 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/20 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/21 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/22 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/23 notconnect 1 auto auto 10/100/1000BaseTXPort Name Status Vlan Duplex Speed Type
Gi1/0/24 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/25 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/26 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/27 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/28 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/29 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/30 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/31 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/32 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/33 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/34 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/35 notconnect 1 auto auto 10/100/1000BaseTXPort Name Status Vlan Duplex Speed Type
Gi1/0/36 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/37 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/38 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/39 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/40 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/41 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/42 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/43 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/44 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/45 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/46 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/47 notconnect 1 auto auto 10/100/1000BaseTXPort Name Status Vlan Duplex Speed Type
Gi1/0/48 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/1/1 notconnect 1 auto auto unknown
Gi1/1/2 notconnect 1 auto auto unknown
Te1/1/3 notconnect 1 auto auto unknown
Te1/1/4 notconnect 1 auto auto unknown
Switch#show pow iModule Available Used Remaining
(Watts) (Watts) (Watts)
------ --------- -------- ---------
1 1440.0 0.0 1440.0
Interface Admin Oper Power Device Class Max
(Watts)
--------- ------ ---------- ------- ------------------- ----- ----
Gi1/0/1 auto off 0.0 n/a n/a 30.0
Gi1/0/2 auto off 0.0 n/a n/a 30.0
Gi1/0/3 auto off 0.0 n/a n/a 30.0
Gi1/0/4 auto off 0.0 n/a n/a 30.0
Gi1/0/5 auto off 0.0 n/a n/a 30.0
Gi1/0/6 auto off 0.0 n/a n/a 30.0
Gi1/0/7 auto off 0.0 n/a n/a 30.0
Gi1/0/8 auto off 0.0 n/a n/a 30.0
Gi1/0/9 auto off 0.0 n/a n/a 30.0
Gi1/0/10 auto off 0.0 n/a n/a 30.0
Gi1/0/11 auto off 0.0 n/a n/a 30.0
Gi1/0/12 auto off 0.0 n/a n/a 30.0
Gi1/0/13 auto off 0.0 n/a n/a 30.0
Gi1/0/14 auto off 0.0 n/a n/a 30.0
Gi1/0/15 auto off 0.0 n/a n/a 30.0
Interface Admin Oper Power Device Class Max
(Watts)
--------- ------ ---------- ------- ------------------- ----- ----
Gi1/0/16 auto off 0.0 n/a n/a 30.0
Gi1/0/17 auto off 0.0 n/a n/a 30.0
Gi1/0/18 auto off 0.0 n/a n/a 30.0
Gi1/0/19 auto off 0.0 n/a n/a 30.0
Gi1/0/20 auto off 0.0 n/a n/a 30.0
Gi1/0/21 auto off 0.0 n/a n/a 30.0
Gi1/0/22 auto off 0.0 n/a n/a 30.0
Gi1/0/23 auto off 0.0 n/a n/a 30.0
Gi1/0/24 auto off 0.0 n/a n/a 30.0
Gi1/0/25 auto off 0.0 n/a n/a 30.0
Gi1/0/26 auto off 0.0 n/a n/a 30.0
Gi1/0/27 auto off 0.0 n/a n/a 30.0
Gi1/0/28 auto off 0.0 n/a n/a 30.0
Gi1/0/29 auto off 0.0 n/a n/a 30.0
Gi1/0/30 auto off 0.0 n/a n/a 30.0
Gi1/0/31 auto off 0.0 n/a n/a 30.0
Gi1/0/32 auto off 0.0 n/a n/a 30.0
Gi1/0/33 auto off 0.0 n/a n/a 30.0
Gi1/0/34 auto off 0.0 n/a n/a 30.0
Gi1/0/35 auto off 0.0 n/a n/a 30.0
Gi1/0/36 auto off 0.0 n/a n/a 30.0
Gi1/0/37 auto off 0.0 n/a n/a 30.0
Interface Admin Oper Power Device Class Max
(Watts)
--------- ------ ---------- ------- ------------------- ----- ----
Gi1/0/38 auto off 0.0 n/a n/a 30.0
Gi1/0/39 auto off 0.0 n/a n/a 30.0
Gi1/0/40 auto off 0.0 n/a n/a 30.0
Gi1/0/41 auto off 0.0 n/a n/a 30.0
Gi1/0/42 auto off 0.0 n/a n/a 30.0
Gi1/0/43 auto off 0.0 n/a n/a 30.0
Gi1/0/44 auto off 0.0 n/a n/a 30.0
Gi1/0/45 auto off 0.0 n/a n/a 30.0
Gi1/0/46 auto off 0.0 n/a n/a 30.0
Gi1/0/47 auto off 0.0 n/a n/a 30.0
Gi1/0/48 auto off 0.0 n/a n/a 30.0
Switch#show module
Switch Ports Model Serial No. MAC address Hw Ver. Sw Ver.
------ ----- --------- ----------- -------------- ------- --------
1 56 WS-C3850-48P-S FOC2225L0AJ b090.7e4f.1200 V07 16.12.13
Switch#show license all
Smart Licensing Status
======================Smart Licensing is ENABLEDRegistration:
Status: UNREGISTERED
Export-Controlled Functionality: NOT ALLOWEDLicense Authorization:
Status: IN-USELicense Conversion:
Automatic Conversion Enabled: False
Status: Not startedExport Authorization Key:
Features Authorized:
<none>Utility:
Status: DISABLEDData Privacy:
Sending Hostname: yes
Callhome hostname privacy: DISABLED
Smart Licensing hostname privacy: DISABLED
Version privacy: DISABLEDTransport:
Type: CallhomeLicense Usage
==============(C3850-48 IP Base):
Description:
Count: 1
Version: 1.0
Status: IN-USE
Export status: NOT RESTRICTEDProduct PID:WS-C3850-48P,SN:FOC2225L0AJAgent Version
=============
Smart Agent for Licensing: 4.8.18_rel/86Reservation Info
================
License reservation: DISABLEDSwitch#show ver
Cisco IOS XE Software, Version 16.12.13
Cisco IOS Software [Gibraltar], Catalyst L3 Switch Software (CAT3K_CAA-UNIVERSALK9-M), Version 16.12.13, RELEASE SOFTWARE (fc1)
Technical Support: (c) 1986-2025 by Cisco Systems, Inc.
Compiled Tue 25-Mar-25 03:05 by mcpre
Cisco IOS-XE software, Copyright (c) 2005-2025 by cisco Systems, Inc.
All rights reserved. Certain components of Cisco IOS-XE software are
licensed under the GNU General Public License ("GPL") Version 2.0. The
software code licensed under GPL Version 2.0 is free software that comes
with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such
GPL code under the terms of GPL Version 2.0. For more details, see the
documentation or "License Notice" file accompanying the IOS-XE software,
or the applicable URL provided on the flyer accompanying the IOS-XE
software.
ROM: IOS-XE ROMMON
BOOTLDR: CAT3K_CAA Boot Loader (CAT3K_CAA-HBOOT-M) Version 6.08, RELEASE SOFTWARE (P)Switch uptime is 3 minutes
Uptime for this control processor is 6 minutes
System returned to ROM by Reload Command
System image file is reload reason: Reload CommandThis product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.A summary of U.S. laws governing Cisco cryptographic products may be found at:
If you require further assistance please contact us by sending email to
(email)
Technology Package License Technology-package
Current Type Next Smart License ipbasek9
None Subscription Smart License None
Smart Licensing Status: UNREGISTERED/EVAL MODEcisco WS-C3850-48P (MIPS) processor (revision AC0) with 794814K/6147K bytes of memory.
Processor board ID FOC2225L0AJ
1 Virtual Ethernet interface
52 Gigabit Ethernet interfaces
4 Ten Gigabit Ethernet interfaces
2048K bytes of non-volatile configuration memory.
4194304K bytes of physical memory.
252000K bytes of Crash Files at crashinfo:.
1611414K bytes of Flash at flash:.
0K bytes of WebUI ODM Files at webui:.Base Ethernet MAC Address : b0:90:7e:4f:12:00
Motherboard Assembly Number : 73-15800-08
Motherboard Serial Number : FOC22236REU
Model Revision Number : AC0
Motherboard Revision Number : B0
Model Number : WS-C3850-48P
System Serial Number : FOC2225L0AJ
Switch Ports Model SW Version SW Image Mode
------ ----- ----- ---------- ---------- ----
* 1 56 WS-C3850-48P 16.12.13 CAT3K_CAA-UNIVERSALK9 INSTALL
Configuration register is 0x102
