Product description
-
Interesting design
All three models of C34 have this design. If you are using a MATX/ITX motherboard, switching to the 5-slot mode will bring about many changes.
- Air cooling / 240 Aio
Air cooling 162mm / ATX,240 Aio. Note that the height of the RAM should be within 44.5mm.
-
The same as C28
Within a length of 335mm If the length exceeds 315mm, the module at the tail end of the case needs to be temporarily removed.
-
Select auxiliary cooling
Fans at each position Multiple fan positions, and basically unaffected by other hardware.
-
Max air
Choose better hardware Whether it is air cooling or integrated water cooling, the small size offers better cooling space.
1 7/5-slot switching 2 Regarding cooling 3 GPU size 4 Fan position 5 Air circulation Three models of C34 comparison
Compact ATX case
Maximum support for ATX motherboards (305*249mm)
Small ATX case + 240 Aio
Maximum support for ATX motherboards (305*279mm)
ATX case + 360 Aio
Maximum support for ATX motherboards (305*279mm)
Radiator
162mm height air cooling / 240,280 Aio (only Matx)
Radiator
162mm height air cooling / 240,280 Aio (only Matx)
Radiator
165mm height air cooling / 240,360,280 Aio (only Matx)
GPU size
Within a length of 335mm
GPU size
Within a length of 385mm
GPU size
At different positions of PSU, the length of GPU is 335/400mm respectively.
Regarding PSU cables
Minimal rear cable clearance — SFX/L PSU or custom cables recommended.
Regarding PSU cables
Tight rear clearance. Use SFX/L PSU, custom cables, or a shorter GPU.
Regarding PSU cables
Rear cable space for flat PSU cables. Use SFX/L if center-mounted
Recommended configuration
Low-heat CPUs; mid-range GPUs; more PCIe; portable.
Recommended configuration
Larger size; high-end GPUs.
Recommended configuration
High-TDP CPUs (360 AIO); smaller PSUs; large GPU compatible.
Recommend ATX 140/150/86mm PSU or smaller SFX/L.
Only supports ATX 140/150/86mm PSU, RAM height ≤44.5mm, 240 AiO thickness ≤55mm. SFX/L recommended.
In 5-slot mode: 240 AiO thickness 25+27+25mm, RAM ≤44.5mm, SFX/L only.
In 5-slot mode, same as option 2.
Dimensions 342 x 182 x 342 mm (L x W x H) Motherboard Support ITX, mATX, ATX Materials Outer Shell: 2mm Aluminum Alloy,Internal Frame: 1.2mm SPCC Steel I/O Panel Metal Power Button (with LED),Audio ,1x TYPE-C (10Gbps),1x USB 3.0 Weight Net: 4.45KG / Gross: 5.55KG PCI-E Slots 7 slots (default), switchable to 5 slots. GPU Max length 335mm (reduce by fan thickness when using front fan). 2.5" Drive Bay 1x on chassis rear (incompatible with 240 AiO setup). 3.5" Drive Bay 1x on bottom-right of chassis. Standard Accessories Removable handle, tempered glass side panel, dust filters, screw box.
- Compact & Highly Compatible ATX Design: Its small form factor saves space without sacrificing performance, supporting standard ATX motherboards, full-size ATX power supplies, and graphics cards up to 335mm in length.
- Built-in Carry Handle for Enhanced Portability: The integrated handle makes it easy to transport your powerful desktop PC to LAN events, between workstations, or simply to rearrange your space with ease.
- Flexible Cooling Support for Air and Liquid: Accommodate high-performance builds with support for a 240mm liquid cooling radiator. When using air cooling, it fits CPU coolers up to 162mm tall and allows for a larger ATX power supply.
- Optimized Interior for Easier Building: The internal layout is designed to simplify the installation process. For the cleanest cable management and easiest build experience, using an SFX/L power supply is highly recommended.
- Attention to Detail & Build Quality: The case features a metal front I/O panel which includes modern ports like a USB 3.0 and a USB Type-C interface, combining functionality with a premium feel.
