BROADCOM 05-25708-00 16 Internal Ports Raid 0/1/5/50/6 Pci-exp 3.0 2g Ddr Iii Md2 12gb/s Sas Controller.

Key Features:

Raid-on-chip Controller: Sas3316 Dual Core Raid On Chip (roc)

Raid Management Software: Megaraid Storage Manager, Storcli (command-line Interface), Ctrl-r (bios Configuration Utility), Hii (uefi Human Interface Infrastructure).

Cache Protection: Optional Cachevault Module (cvpm02)

Physical Dimensions: Low Profile 6.127” X 2.712”

Host Bus Type: X8 Lane Pci Express® 3.0

Cache Memory: 2gb 1866mhz Ddr3 Sdram

Internal Ports: 16

Data Transfer Rates: Up To 12gb/s Per Port

Devices Supported: Up To 240 Sata And/or Sas Devices

Internal Connectors: 4 Mini-sas Hd Sff8643

Mtbf: > 2,500,000 Hours

Operating Temperature: Maximum Ambient: Controller Card: 55°c, With Optional Cachevault Accessory (lsicvm02) 55°c Maximum Ambient: Controller Card: 60°c (44.5°c With Lsiibbu07)

Operating Voltage (v): +12v, +3.3v

Os:extensive Support Includes Microsoft Windows Vista/2008/server 2003/2000/xp, Linux, Solaris (x86), Netware, Freebsd, Vmware And More. Visit The Downloads Page For The Most Complete List Of Supported Operating Systems
