BEC RidgeWave® 6900R21-G LTE-A Pro CBRS Outdoor Router (New, Open Box)
Opened to inspect contents.

TheBEC RidgeWave® 6900R21-G LTE-A Pro CBRS Outdoor Router bring secure, high performance mission-critical cellular connectivity to outside locations and harsh environments. The rugged, compact IP68 rated enclosure enables it to stand up to dirt, harmful ingress of water, humidity and extreme temperatures for years of dependable operation. The RidgeWave® by BEC 6900R21 is the ideal solution for industries, businesses, remote locations, residences, rural areas and the underserved.

Key Features

Designed for Challenging and RuggedDeployments

• IP68 hardened enclosure with Industrial-grade components •
• Designed for the toughest industrial environments
• Rugged compact design, deploys easily in space-constrained areas
• Electrostatic Discharge (ESD) & Surge protection
• IEEE 802.3at Power over Ethernet (PoE)

High Performance and Support for LTE TDDBands 42, 43 & 48

• Category 12 UE with Carrier Aggregation, data rates of up to 430Mbps (DL) / 20Mbps (UL)
• Advanced IP networking functionalities including bridge and router modes
• Deploy LTE Bands 42/43 now and upgrade to LTE Band 48 later
• Advanced secure VPN sessions (Optional)

Patented Dual-Polarization AntennaTechnology

• Ensure e cient bi-directional transmission for maximum bandwidth and coverage
• H-Plane & V-Plane Polarization
• Simplicity and high isolation for stable and reliable connections

Ideal Use Case

• Fixed Wireless Broadband
• Last Mile Access
• Mission-critical, performance-intensive networks
• Industrial Connectivity Applications
• Urban and Rural Environments
• Package includes Gigabit PoE injector and mounting kit

Network Certification: FCC Part 96 Authorized CAT B CPE-CBSD, OnGo

Supported Frequency Bands

• Comply 3GPP Rel.12 with Carrier Aggregation
• 4G/LTE: TDD (Cat.12)
  B48 (3550MHz ~ 3700MHz)
• Data Rates of 430Mbps and 20Mbps UL (TDD Config. 2, SSF: 7)
• Carrier Aggregation:3CA DL/2CA UL
• LTE Bandwidth: 1.4MHz, 3MHz, 5MHz, 10MHz, 15MHz & 20MHz
• Modulation: 256QAM DL / 64QAM UL
• Maximum Transmit Power: 38dBm EIRP
• LTE Antenna
  MIMO Directional (Dual Polarization)
  4×4 MIMO DL
  Gain: 15.5dBi ± 1dBi
  CPE-CBSD Category B

Operational Modes

• Bridge or Routed

Network Protocols and Features

• NAT, static routing and RIP-1/2
• NAT supports PAT and multimedia applications
• Virtual server and DMZ
• SNTP, DNS relay and DDNS
• IGMP snooping and IGMP proxy
• Supports DHCP server/client/relay

Quality of Service Control

• Supports the DiffServ approach
• Traffic prioritization based-on protocol, port number, and IP address

Firewall

• Built-in NAT Firewall
• Stateful Packet Inspection (SPI)
• Prevents DoS attacks including Land Attack, Ping of Death, etc.
• Access Control
• IP Filtering, MAC Filtering, URL Filtering
• Password protection for system management
• VPN pass-through

Management

• Web-based GUI for remote and local management
• Firmware upgrade & configuration data upload and download via web-based GUI
• BECentral® Cloud Management
• Syslog monitoring

Physical Interface

• Gigabit LAN Interface with IEEE 802.3at compliant PoE P.D
• SIM:One (1) slot 2FF Size
• GPS (6900R21-G Only)
• LED Indicators: Power, LAN(PoE), LTE, and Internet
