WAVLINK · WiFi 6 & WiFi 7 ROUTER SERIESWiFi 6 & WiFi 7 Mesh RouterAX3000 · AX6000 · AX6000 AI QoE · BE3600 WiFi 7Four configurations spanning Gigabit to 2.5G WAN, up to 6000Mbps dual-band throughput, and up to 256 connected devices — all backed by Everything Mesh and WPA3 security.⚡ Up to 6000Mbps📡 Everything Mesh🔒 WPA3 Security🖥 Up to 256 Devices🌐 2.5G Port Options3000MbpsAX3000 WiFi 66000MbpsAX6000 WiFi 63600MbpsBE3600 WiFi 7256Max Devices2150sq.ftCoverageSelection GuideChoose Your Port ConfigurationAll four routers share WiFi 6 / WiFi 7 radios and Everything Mesh. The main difference is the WAN speed and port layout.AX3000 WiFi 6 Router / 1G WAN + 2× 1G LAN· MIGHTY EX1 PRO • 2976Mbps dual-band — 574Mbps @ 2.4GHz + 2402Mbps @ 5GHz.
• 1 × Gigabit WAN + 2 × Gigabit LAN for wired PCs, smart TVs and consoles.
• 1.3GHz dual-core processor handles whole-house coverage and AR/VR gaming.
• VPN-ready: OpenVPN Client/Server, WireGuard Client/Server, ZeroTier.
• AdGuard Home supported — global DNS-level ad and tracker blocking.
• Best for: standard homes, budget WiFi 6 upgrade, replacing an aging ISP router.AX6000 WiFi 6 Router / 2.5G WAN + 4× 1G LAN + USB 3.0 • 5952Mbps with 160MHz channels — 1148Mbps @ 2.4GHz + 4804Mbps @ 5GHz.
• 2.5G WAN + 4 × Gigabit LAN + USB 3.0 for maximum wired flexibility.
• 8 × 5dBi antennas with beamforming — coverage up to 2,000 sq.ft.
• OFDMA + 4×4 MU-MIMO — more than 256 devices simultaneously.
• PPTP, L2TP, OpenVPN and WireGuard support with WPA/WPA2-Enterprise.
• Best for: gigabit-plus fiber plans, NAS users, heavy multi-device households.AI QoEAX6000 WiFi 6 Router / 2.5G WAN/LAN + 3× 1G LAN + USB 3.0 Giant Stream6 • 6000Mbps dual-band — 1147Mbps @ 2.4GHz + 4803Mbps @ 5GHz.
• 1 × 2.5G WAN + 1 × 2.5G LAN + 3 × 1G LAN + USB 3.0 — the richest port set.
• AI QoE automatically prioritizes gaming, streaming and video meetings.
• 8 × 5dBi antennas with 4×4 MU-MIMO — coverage up to 2,150 sq.ft.
• 4 modes: Router, AP, Repeater and Everything Mesh.
• Best for: prosumers with multi-gig internet, demanding smart homes, home offices.WiFi 7BE3600 WiFi 7 Router / 1G WAN + 3× 1G LAN • WiFi 7 (802.11be) — 688Mbps @ 2.4GHz + 2882Mbps @ 5GHz.
• MLO dual-band aggregation blends 5GHz + 2.4GHz for lower latency and stability.
• 1 × Gigabit WAN + 3 × Gigabit LAN for consoles, streaming players and PCs.
• OFDMA + UL/DL MU-MIMO — 32+ devices share the network concurrently.
• Guest WiFi, VLAN, AdGuard Home, Remote Access, Parental Controls, QoS.
• Best for: future-proof WiFi 7 adoption, mesh-ready homes, VLAN-segmented networks.Side by SideCompare All Four ModelsParameterAX3000AX6000AX6000 AI QoEBE3600 WiFi 7WiFi StandardWiFi 6 (ax)WiFi 6 (ax)WiFi 6 (ax)WiFi 7 (be)Total Speed574Mbps1148Mbps1147Mbps688Mbps5GHz Port1 × 1G1 × 2.5G1 × 2.5G1 × 1GLAN Ports2 × 1G4 × 1G1 × 2.5G
+ 3 × 1G3 × 1GUSB Port—USB 3.0USB 3.0—Antennas4 × 5dBi Ext
+ 1 × 5dBi Int8 × 5dBi8 × 5dBi5dBi OmniCoverage2,000 sq.ft2,000 sq.ft2,150 sq.ft1,700 sq.ftMax Devices256256+25632+Key MU-MIMO
160MHzAI QoE
4×4 ModesRouter / AP / Repeater
Everything MeshEverything Mesh
(extender-ready)Router / AP / Repeater
Everything MeshEverything Mesh
(single WiFi MIXWPA2/WPA3-PSK MIXWPA2/WPA3-PSK MIX
WPA/WPA2-EntVPN Support✓ ✓ ✓ ✓ AdGuard Home✓——✓Power AdapterDC 12V / 1ADC 12V / 1.5A
18WDC 12V / 1.5A
18WIncludedDimensions17.5 × 12.5 × 3.5 cm
foldable23.5 × 15.6 × 4 cm
w/o antennas20.5 × 20.5 × 16 cm
w/o antennas16.8 × 16.8 × 3.3 cm
w/o antennasWeight253 g / 8.9 oz462 g / 16.3 oz751 g / 26.5 oz396 g / 14 ozCore PlatformEverything You Need in One RouterShared technologies that carry across the whole WAVLINK router lineup.📡WAVLINK Everything MeshCreate a high-speed whole-home WiFi experience with one network name and password across every node. Add a mesh extender anytime to eliminate dead zones and walk from room to room without switching networks.⚡More Connection, Less LatencyOFDMA + MU-MIMO dramatically reduce network congestion by letting far more devices share the airtime simultaneously. Say goodbye to buffering when everyone streams, games and works from home at once.🔒Advanced WPA3 EncryptionThe latest WPA3 security protocol protects your network from hackers and malware, with WPA2 / WPA backward compatibility so every device on your network stays connected.⚙Simple Setup & ManagementConfigure everything through the WavRouter app or the browser-based UI at 192.168.20.1. Guided steps, parental controls and QoS settings keep network management straightforward — no technical expertise required.🌐Get a New Router, Keep Your AccountConnect the WAN port of your old router to the LAN port of the WAVLINK router, then click “Get account from the old router” on the network settings page to scan and sync your ISP account and password automatically.🌡Optimal Thermal PerformanceSuper heat dissipation with a large number of hidden grilles and a large-area heat-dissipation aluminum case, ensuring smooth operation and prolonging the service life of your router.SpecificationTechnical DetailsParameterAX3000AX6000AX6000 AI QoEBE3600ModelWL-WN586X3-B
MIGHTY EX1 PROWL-WN536AX6WL-WN592AX6
Giant Stream6WL-WN530BE1Wireless StandardIEEE 802.11 b/g/n/a/ac/axIEEE 802.11 b/g/n/a/ac/ax/beFrequency / Speed2.4G 574 +
5G 2402Mbps2.4G 1148 +
5G 4804Mbps2.4G 1147 +
5G 4803Mbps2.4G 688 +
5G 2882MbpsButtonsReset / PairPower On/Off
Reset / Pair / TurboReset (6s)
Pair (2s)Reset (6s)
Pair (2s)Status LEDsBlue4 LAN, WAN, WiFi
Power, StatusBlue status LEDsBlue status LEDsEthernet Cable100cm / 39.4in includedIn the BoxWhat You’ll ReceivePackage contents vary slightly by model — refer to the column that matches your selection.ItemAX3000AX6000AX6000 AI QoEBE3600WiFi Router (model per your selection)1111Power Adapter1111Ethernet Cable1111Quick Start Guide / Manual1111Safety NotesBefore You Buy01Speed ratings: quoted wireless speeds are theoretical maximums under ideal lab conditions. Real-world throughput depends on your ISP plan, distance, building materials and channel congestion.02Mesh compatibility: Everything Mesh only pairs with WAVLINK devices that support the same Mesh technology. Check the model compatibility list before adding extender nodes.032.5G ports: to fully benefit from a 2.5G WAN/LAN port, both your ISP modem and connected devices must support 2.5G. Using CAT6 or above Ethernet cables is recommended.04WiFi 7 MLO: the BE3600 requires compatible WiFi 7 client devices to take advantage of MLO dual-band aggregation. Standard WiFi 6/5 devices will still connect but at their own native speeds.05AdGuard Home: supported on the AX3000 (WN586X3-B) and BE3600 (WN530BE1). First-time setup is at 192.168.20.1:3000.06Configuration: set up via the WavRouter app or by connecting to the router’s WiFi and visiting 192.168.20.1 in a browser.WAVLINKWiFi 6 & WiFi 7 MESH ROUTER SERIES · AX3000 · AX6000 · BE3600
