Model X8000A506-18

Type ATX

Modular Fully

Dimension (W x L x H) 150x 170 x 86mm

Warranty 10years

Input Voltage 100-240

Input Current 15A ~7.5A

Input Frequency Range 47Hz~ 63Hz

PFC APFC

PFC at half / full load:

>0.95 at AC 110v 60Hz(typical)

>0.90 at AC 230v 50Hz(typical)

Power Good Signal 100~ 500mS

Efficiency At20% / 50% / 100% load AC 115V internal,

the power efficiency should be at least 90% / 92% / 89%.

Protection OCP/ OVP / UVP / SCP / OPP / OTP / SIP / NLO

Output Capacity 1300W

Operation Temperature 0~ 40°C

Regulatory cTUVus/ TUV / CB [IEC62368 Compliant] / CE /

FCC / BSMI / 3C / KC / RCM

Fan 135 x 135 x25(mm) FDB Silent Fan

Certifications 80Plus Platinum

Connector 1 xMB 24(20+4) Pin

2 x 8(4+4) Pin EPS 12V

12 x 8(6+2) Pin PCI-E

14 x SATA

5 x Molex

1 x FDD

UPC# 0-761345-11705-0SP1300

0-761345-11706-7 SP1300 AU

0-761345-11707-4 SP1300 EC

0-761345-11708-1 SP1300 GB

0-761345-11709-8 SP1300 JP

Net Weight 2.12Kgs

Gross Weight 4.05Kgs
