AUO M270HAN01.1 Non-Touch Screen LCD Panel Replacement for HP 27-D Series
Price: US $194.99
BrandAUO
Diagonal Size27.0 inch
Typea-Si TFT-LCD, LCM
Pixel Format1920(RGB)×1080 [FHD] 81PPI
ConfigurationRGB Vertical Stripe
Active Area597.888(H)×336.312(V) mm
Outline Dim.607.1(H)×354.1(V) ×13.2(D) mm
Bezel Area-
TreatmentAntiglare, Hard coating (3H)
Luminance250 cd/m² (Typ.)
Contrast Ratio1000:1 (Typ.) (TM)
View DirectionSymmetry
Response Time14 (Typ.)(G to G)
Viewing Angle80/80/80/80 (Typ.)(CR≥10)
Operating ModeAHVA, Normally Black, Transmissive
Support Color16.7M 72% NTSC
Light SourceWLED [17S4P] , 30K hours , W/O Driver
Weight3.12Kgs (Typ.)
Designed For
Frame Rate60Hz
Touch PanelWithout
Interface Type
LVDS (2 ch, 8-bit) , 30 pins Connector
Power Supply
5.0V (Typ.)
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
