Motherboard chip
Integrated chip
Sound/network card
Main chipset
Intel C602
Chip manufacturers
Intel
Chipset description
Powered by Intel C602 chipset
Audio chip
Integrated Realtek ALC898 8-channel audio chip
Network chips
Onboard Intel 82574L dual Gigabit network card
CPU specifications
Applicable Platforms
Intel
CPU type
Xeon E5-2600
CPU description
Support for Intel 32nm processors
CPU socket
LGA 2011
Number of CPUs supported
2
Memory specifications
Memory type
DDR3
Memory description
8×DDR3 DIMMs
support up to 64GB memory, support quad-channel DDR3 2133 (overclocking)/2000 (overclocking)/1866 (overclocking)/1600/1333/1066MHz memory
Expansion slots
Video card slot
7× PCI-E X16 graphics card slot
SATA interface
8× SATA II interface; 6× SATA III interface
I/O interface
USB interface
10× USB2.0 interface (4 built-in + 6 backplane); 4× USB3.0 interface (2 built-in + 2 backplane)
PS/2 interface
PS/2 keyboard and mouse universal interface
Other internal sockets
2×RJ45 network interface
1× optical fiber interface
External port
Audio interface
Form factor
Motherboard form factor
EEB form factor
Form factor
30.5×33.0cm
Software management
BIOS performance
64Mb Flash ROM, UEFI BIOS, PnP, DMI 2.0, WfM2.0, SM BIOS 2.6, ACPI 2.0a, Multi-Chinese BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
Other features
Other features
Support RAID 0,1,5,10 Support AMD Quad-GPU CrossFireX dual-card quad-core crossfire technology
Support NVIDIA SLI quad-way crossfire technology
Other parameters
Power outlet
Two eight-pin, one 24-pin power connector
Power supply mode
7+1 phase
annex
Random attachments
ASUS motherboard x1
User Manual x1
I/O bezel x1 SATA 3.0Gb/s data cable x8
SATA 6.0Gb/s data cable x6
COM port cable(s) x2
3-way SLI bridge x1 SLI bridge x1
4-way SLI bridge x1
2port USB2.0+1394 extension cable x1
