DeskMeet X300 SeriesMeet the Versatile PC
With just 8 liters of volume, DeskMeet is a powerful and compact desktop PC designed to deliver the best experience for daily computing, gaming, home entertainment, content creation and business. It supports the desktop processor and the graphics card under 20 cm long. This chassis can stand either vertically or horizontally to fit into any workspace and give users a neat and tidy desk space.
Processing Power
DeskMeet X300 supports the latest AMD Ryzen™ 5000 Series desktop processor (up to 65W) that delivers ultimate performance for efficient work and demanding applications.
* DeskMeet has a CPU cooler height limitation of 54mm (supports AMD Wraith Stealth CPU cooler)
Incredible Memory Performance
Up to 128GB of four DIMM memory clocked at 3200MHz, DeskMeet provides a faster multitasking experience and a responsive system.
Get the server-grade performance and rock-solid durability with support of ECC un-buffered memory modules for high-end computing systems, such as scientific or financial computers.
* ECC support varies by CPU.
Heatsink
DeskMeet features a dedicated MOSFET heatsink that allows it to dissipate excess heat and operate at the optimum temperature for reliable performance.
Ready for Dual slot Graphics Card
DeskMeet can fit a dual slot graphics card (up to 20cm or 7.87 inches) which is an option for those requiring advanced graphics performance for heavy visual tasks, such as gaming, 3D rendering and video editing.
Efficient Airflow Design
DeskMeet features air vents at the top, left side and bottom of the chassis, allowing for maximum heat removal and constant airflow.
In addition, the custom intake fan inside the power supply can pull in cool air to dissipate heat from the CPU and VRM. Such optimized thermal design enables the system to run cool and quiet without compromising performance.
Expand the Configurations Potential
With a flexible and expandable design, DeskMeet can be easily configured to meet users now and future needs. The mounting holes on top of the frame provide four options, 1 x 3.5” HDD*, 2 x 2.5” SSD/HDD, 1 x 120mm fan or 1 x single radiator liquid cooler (Max height of radiator + fan ? 45mm).
* Supports standard mounting holes 3.5” HDD only
Up to Three Storages
DeskMeet X300 supports up to 3 storages including 1 x Ultra M.2 to speed up the system and reduce loading time, 2 x SATA 6Gb ports (supports RAID 0/1 function) for 3.5” HDD or 2.5” SSD/HDD enable users to build a mini data center.
- M2_1 M.2 (2280) –PCIe Gen3 x2/x4
- 2 x SATA 6Gb SSD/HDD
Easy to set up and upgrade
DeskMeet adopts a drawer chassis design so users can pull out the motherboard tray after removing one screw at the bottom. To keep up the system in the latest status, all the components can also be installed or upgraded with ease. DeskMeet provides a simple setup experience to save time and effort.
Keep Your 3.5” HDD
DeskMeet can be equipped with 2 x 3.5” HDD at most. When users replace the aged tower PC with DeskMeet, they can install their old 3.5” HDD to preserve personal data.
ATX Power Supply
DeskMeet includes an internal 500W 80 Plus Bronze power supply with custom length cables to save space and make cable management easier. The fan in the power supply will draw in the cool air to CPU cooler which is the best way to increase airflow and ensure DeskMeet operates at its utmost efficiency of heat dissipation.
Multi-Monitor
Up to three displays can be used simultaneously without adding an extra graphics card. With multi-screen, you can have high productivity and immersive gaming experience.
Front USB Type-C
DeskMeet features one reversible USB Type-C port in the front of the case for fast charging and data transfer.
Connectivity
Although DeskMeet’s compact size, it doesn’t compromise on I/O ports. It has eight Type-A USB ports to connect to all of your peripheral devices.
A Perfect Match for Content Creation
Intel® Arc A380 is the world’s first graphics card offering hardware-accelerated AV1 encoding. With AV1 support, you can accelerate creation tasks up to 4.4 times faster compared to software encoding.* DeskMeet equipped with Intel® Arc A380 Challenger ITX 6GB OC (19cm) is the best solution for content creator, especially streamer. They can produce high quality AV1 content more efficiently and effortlessly.
* According to Intel® PC for Various Applications
With only 8 liters and 168mm in width, DeskMeet is a portable PC that you can place it in dormitory or hand baggage* when taking a trip to play video game at the hotel room. DeskMeet offers a wide range of uses for any scenario.
* The total weight of DeskMeet is 4.5kg (All components, graphics card and PSU are installed) which does not exceed 7kg weight limit for hand baggage.
DeskMeet Addressable LED(Optional)
Exclusive Addressable RGB LED Strip for ASRock DeskMeet Series mini PC. Attach the magnetic strip inside the chassis to create cool personalized lighting for you.
* The availability of ARGB LED Strip may vary by region.
M.2 Wi-Fi Kit(Optional)
ASRock M.2 Wi-Fi Kit includes Intel® M.2 Wi-Fi module and two antennas; offering wireless connectivity for DeskMeet.
Intel® AX210 or Intel® AC3168
The availability of M.2 Wi-Fi Kit may vary by region.
Auto Driver Installer
No need to worry about lack of disk drive! Asrock preinstall LAN driver to ensure that you are able to install all drivers needed in an easier way than using SCD.
Step1: Install Auto Driver Installer
Step2: Update drivers needed
Step3: Done!
Notes:
The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
Learn more about ASRock DESKMEET X300W/B/BB/BOX/USBest Seller Ranking#12 in <a {$BestSellingURL} class="link-text">Mini-PC X300W/B/BB/BOX/USCPU SupportedCPU TypeSupports AMD Ryzen 2000 / 3000 / 4000 G-Series / 5000 / 5000 G-Series ProcessorsCPU SocketAMD Socket AM4ChipsetNorth BridgeAMD X300Memory SupportedMemory installedNo MemoryMemory slot4 x 288Pin DIMMMemory Type SupportedAMD Ryzen 5000/4000 series - 3200MHzAMD Ryzen 3000/2000 series - 2933MHzMax Memory Supported128GBDual Channel Memory SupportedYesExpansion SlotsPCI Express 3.0 x161 x PCI Express 3.0 x16Other1 x M.2 (key E 2230) slot for Wi-Fi + BT ModuleStorageStorage InstalledNo Hard DriveSerial ATA2 x SATA 6.0Gb/sM.2 Slot1 x Ultra M.2 (2280) PCIe Gen3 x4 slotSATA RAIDRAID 0, 1AudioOnboard AudioRealtek ALC897CommunicationsLANRealtek RTL8111HMax LAN Speed1GbpsFront Panel PortsFront USB1 x USB 3.2 Gen1 Type-C2 x USB 3.2 Gen1 Type-A2 x USB 2.0 Type-AFront Audio Ports1 x Headphone/Headset JackBack Panel PortsVGA1 x D-subHDMI1DisplayPort1 x DisplayPortRear USB2 x USB 2.02 x USB 3.2 Gen1 Type-ARJ451Rear Audio Ports1 x Audio Jack (Line out)Other Rear PortsConnectors:1 x Chassis Intrusion Header1 x CPU Fan Connector (4-pin)1 x Chassis/Water Pump Fan Connectors (4-pin)1 x 24 pin ATX Power Connector1 x 8 pin 12V Power Connector1 x Front Panel Header1 x USB 2.0 Headers (Support 2 USB 2.0 ports) (Supports ESD Protection)1 x COM Port Header (Optional for X300-ITX/COM model)Power SupplyPower Supply500W power supply (80+ Bronze, peak 550W)Physical SPECDimensions8.59" x 6.61" x 6.61" (excl. Protrusions)8.72" x 6.61" x 9.30" (incl. Installation Guide2 x SATA Data Cables1 x Screws Package1 x Intel AC-3168 Wi-Fi KitAdditional InformationFirst Listed on NeweggJuly 08, 2022ShippingEnjoy fast and reliable shipping when you buy your products from Newegg. Our ordering and shipping services are among the best in the industry due to short processing times and a variety of shipping methods. Your orders are packaged at one of the many local warehouses across the country, minimizing delivery times and ensuring you get your purchases as soon as possible.PaymentsNewegg has partnered with PayPal to offer you the very best in payment services. PayPal allows you to buy with confidence, knowing your payments are processed quickly and securely with state-of-the-art encryption technology.ReturnReturns are subject to restocking fees of 15% - 30% of the purchase price and return shipping fees. For products that are eligible for return for replacement, the return shipping labels are free for returns for replacement of the same item within the applicable return policy period. Newegg does NOT charge for restocking fees or return shipping labels for returns of defective products, or if you received the wrong product, the product did not match what was shown on the Site, or we made some other shipping error, provided the item is returned within its return policy period, and in accordance with the Return Policy. For international buyers, items shipped internationally do not qualify for manufacturer warranties.
