Manufacturer: APC
Model: APC Smart-UPS SRT 5000VA isolation step down transformer 208V/240V to 120V Rack or Tower
Condition: Refurbished
Part Number: SRT5KTF
Warranty: 1 Year Full Replacement Warranty
Description: The APC SRT5KTF is a 5kVA isolation and step-down transformer designed for APC Smart-UPS SRT systems. It supports 208V and 240V input power and provides 120V, 208V, and 240V output power for mixed-voltage environments. Featuring a NEMA L6-30P input connection and multiple output receptacles, including (8) NEMA 5-20R, (2) NEMA L6-20R, (1) NEMA L6-30R, and (1) NEMA L14-30R, the SRT5KTF provides flexible power distribution for servers, networking equipment, telecommunications systems, and other critical applications. The transformer can be installed in either rackmount or tower configurations and includes selectable 208V/240V input operation. Refurbished and backed by a 1 Year Full Replacement Warranty
APC Smart-UPS SRT Step-Down Transformer 5kVA SRT5KTF User's Manual
SRT5KTF - APC Smart-UPS SRT 5kVA Specifications:
Key Features Transformer TypeIsolation / Step-Down Transformer Form FactorTower Capacity5000VA / 5kVA Input Voltage208V / 240V Output Voltage120V / 208V Additional Output Voltage240V Input ConnectionNEMA L6-30PTotal Output Receptacles12 Rackmount Kit SupportYes Input Nominal Input Voltage208V / 240V Input Frequency50/60 Hz Input Connection TypeNEMA L6-30P Cable Length3 ft (0.91 m) Number of Power Cords1 Input Voltage SelectionUser Selectable 208V or 240V Output Output Voltage120V / 208V Additional Output Voltage240V Total Output Receptacles12 Output Connections(8) NEMA 5-20R (2) NEMA L6-20R (1) NEMA L6-30R (1) NEMA L14-30R Isolation TransformerYes Step-Down Function208V/240V to 120V Power DistributionMixed Voltage Output in (43.2 cm) Width5.12 in (13.0 cm) Depth25.98 in (66.0 cm) Net Weight125 lbs (56.7 kg) Mounting ModeRack-Mounted with Kit - Optional Tower InstallationSupported Mounting PreferenceNo Temperature32°F to 104°F (0°C to 40°C) Storage Temperature5°F to 113°F (-15°C to 45°C) Operating Humidity0% to 95% Non-Condensing Storage Humidity0% to 95% Non-Condensing Operating AltitudeUp to 10,000 ft Storage AltitudeUp to 50,000 ft (15,240 m) Conformance Product FamilySmart-UPS SRT Year Full Replacement Warranty Included
