Product Description
Android panel pc CPU Onboard RK3288 28nm Quad core ARM Cortex A17 1.8 GHz Memory 2GB NAND FLASH EMMC FLASH 16GB GPU Quad-Core Mali-T764 3D GPU Support OpenGL ES1.1/2.0/3.0, OpenVG1.1, OpenCL1.1 and Renderscript , Directx11, 2D GPU support 8Kx8K
input，4Kx4Koutput Audio Realtek ALC662, High Definition Audio (HD), Line in, Line out I/O Interface USB ,Lan(RJ45),COM(RS232), /TF slot ,HDMI/Audio OUT/POWER DC,WIFI,Bluetooth Opetation System Android 8.0 Panel size 24" inch Resolution 1920x1080, Brightness control Light sensor for auto dimming Response time 15ms Contrast ratio 1000:1 View angle 80°/80°/70°/70° (R/L/U/D) Touch panel Touch Type 10 points Multi Capacitive / Resistive / touch screen optional Touch Interface USB Response time <8ms Luminousness 75-85% Power Supply External Power Supply AC 100 - 240V Working voltage DC Power consumption ≤60W Operating Environment Temperature range Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
Relative humidity 5%~95% @ 40° C, non-condensing Vibration 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis Packing Details Accessories Power adapter, Wifi antenna Other Mounting (options) 1) provide wall brackets for wall-mounting, VESA 100×100mm 2) provide Floor standing to support the PC Certification CE, FCC，ROHS
