TheUbiquiti UniFiAI Port(UP-AI-Port) is an AI appliance designed to enhance any UniFi or third-party camera with AI detection, classification, and recognition capabilities.

Each AI Port currently supports one ONVIF or UniFi Protect G3/G4/G5 camera to ensure optimal AI processing performance. Future Protect updates will expand the capacity to support multiple cameras.the AI Port works seamlessly with any compatible camera on the same network (wired or wireless), providing flexible installation options. Cameras directly connected to the AI Port still need to be paired with the AI port in Protect.

• When powered via PoE+: Up to 12.95W.
• When powered via PoE++: Up to 25.5W.

For cameras requiring higher power, use a separate PoE switch or injector.The AI Port automatically detects the highest and lowest resolution streams on the camera and assigns them to the HQ and LQ streams in Protect. If the streams are adjusted on the camera, the device must be removed and re-adopted in Protect to see the changes.The AI Port supports PTZ controls on ONVIF third-party cameras andsupports resolutions up to 4K (3840 x 2160) and 30 FPS. For higher performance cameras, reduce the resolution and FPS before connecting to the AI Port.Edge recording will be available in a future update using the provided SD card slot.The AI Port is optimized for single-stream cameras that have aspect ratios within 3840 x 2160. Multisensor cameras with very wide aspect ratios are not compatible.

In future Protect updates, the AI Port will support the following number of cameras. Third party cameras cannot be mixed with Protect cameras.

• ONVIF 2K: Up to 2 cameras
• ONVIF HD: Up to 3 cameras
• Protect Cameras: Up to 5 cameras

The AI Port enhances all compatible cameras with:

• Detections:Motion, people, vehicles, animals, speech.
• Classifications:Vehicle color, vehicle type.
• Recognition:Face recognition, license plate recognition.

Additional recognitions added by the AI Port are available inCamera Settings.

Key Features:

• Camera Compatibility: Compatible with ONVIF third-party cameras.
• Advanced AI: Provides face and license plate recognition.
• Power Input: (1) PoE++/PoE+ power input.
• Power Output: (1) PoE+/PoE power output.
• Connectivity: Can directly connect or pair with a camera on the network.

Technical Specifications:
Mechanical:

• Dimensions:
  • Without mount: 150 x 64 x 38.4 mm (5.9 x 2.5 x 1.5")
  • With mount: 152.7 x 69 x 47.8 mm (6 x 2.7 x 1.9")
• Weight:
  • Without mount: 258.3 g (9.1 oz)
  • With mount: 294 g (10.4 oz)
• Enclosure Material: Polycarbonate
• Mount Material: Polycarbonate
• Pole Mount Diameter: >45 mm (1.8") on pipe outer diameter

Hardware:

• Networking Interface: (1) GbE RJ45 port
• Max. Camera Resolution:
  • Width: 3840 pixels
  • Height: 2160 pixels
• Power Method:
  • PoE
  • PoE+ input required for PoE output (12.95W)
  • PoE++ input required for PoE+ output (25.5W)
• LEDs: Blue/white
• Button: Factory-reset
• Ambient Operating Temperature: -20 to 40° C (-4 to 104° F)
• Ambient Operating Humidity: 20 to 90% noncondensing
• Certifications: FCC, IC, CE

Software:

• Web Application: UniFi Protect: Version 5.1 and later
• Mobile App: UniFi Protect iOS™ and Android™

Description:

• Full Product Name:Protect AI Port
• Full Description: AI appliance that enhances any UniFi or third-party camera with AI detection, classification, and recognition capabilities.
