Processor/Cache
CPU

• 8th/9th Generation Intel® Core™i3/Pentium®/Celeron® Processor, Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor
• Single Socket LGA-1151 (Socket H4) supported, CPU TDP supports Up to 95W TDP

Cores / Cache

• 6 cores, 12 threads

Note

• BIOS version 1.0b or above is required to support Intel® Xeon® E-2200 and 9th Generation Intel® Core™ i3/Pentium®/Celeron® Processors

System Memory
Memory Capacity

• Up to 64GB Unbuffered ECC UDIMM, DDR4-2666MHz, in 2 DIMM slots

Memory Type

• 2667/2400/2133MHz ECC DDR4 SDRAM 72-bit

DIMM Sizes

• 4GB, 8GB, 16GB, 32GB

Memory Voltage

• 1.2V

Error Detection

• Corrects single-bit errors

On-Board Devices
Chipset

• Intel® C242

SATA

• Intel® C242 controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10

IPMI

• ASPEED AST2500

Network Controllers

• Dual LAN with 1GbE with Intel® I210

Graphics

• ASPEED AST2500 BMC

Input / Output
USB

• 4 USB 2.0 ports (2 rear + 2 via headers)
• 7 USB 3.2 Gen2 ports (2 rears (2 Rear Type A + 2 via headers + 1 Type A)

Video Output

• 1 VGA port

Serial Port / Header

• 1 COM Port (1 rear)


TPM

• 1 TPM Header

Expansion Slots
PCI-E

• 1 PCI-E 3.0 x16 (in x16 slot)

M.2

• M.2 Interface: 1 SATA/PCI-E 3.0 x4
• Form Factor: 2280
• Key: M-Key
• Double Height Connector

System BIOS
BIOS Type

• UEFI 256Mb

BIOS Features

• ACPI 6.0
• SMBIOS 2.7
• Plug and Play (PnP)
• RTC (Real Time Clock) Wakeup
• UEFI 2.7
• USB Keyboard support
• PCI 3.0

Management
Software

• IPMI2.0, KVM with dedicated LAN, SSM, SUM, SuperDoctor® 5, Watchdog

Power Configurations

• ACPI Power Management
• Power-on mode for AC power recovery

PC Health Monitoring
Voltage

• +12V, +3.3V, +5V, +5V standby, 4 -fan status, Chassis intrusion header, Chipset Voltage, Memory Voltages, Monitors CPU voltages, Supports system management utility, System level control, VBAT

Temperature

• Thermal Monitor 2 (TM2) support, CPU thermal trip support, PECI, Monitoring for CPU and chassis environment

LED

• CPU / System Overheat LED, UID/Remote UID

Other Features

• ACPI power management, Chassis intrusion detection, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, Dual Cooling Zones, M.2 NGFF connector, UID, WOL

• 5% - 95% (non-condensing)

Operating Environment
Operating Temperature Range

• 0°C ~ 50°C (32°F ~ 122°F)

Non-Operating Temperature Range

• -40°C - 70°C (-40°F - 158°F)

Operating Relative Humidity Range

• 8% - 90% (non-condensing)

Non-Operating Relative Humidity Range
Physical Stats
Form Factor

• Mini-ITX

Dimensions

• 6.7" x 6.7" (17.02cm x 17.02cm)
