• Form Factor: External
• Localization: United States
• Data Link Protocol: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
• Frequency Band: 2.4 GHz, 5 GHz
• Capacity Concurrent users: 100 ¦ VoIP calls: 30 ¦ BSSIDs per radio: 8
• Power Over Ethernet (PoE): Supported PoE+

Features:Integrated BeamFlex+ Smart Antenna Technology

• BeamFlex+ support for up to 4 dB of signal gain and 10 dB of interference mitigation in addition to the antenna gain
• Polarization Diversity with Maximal Ratio Combining (PD-MRC) ensures reliable connectivity for mobile devices

Superior, Fast Wi-Fi Connectivity

• 802.11ac 2X2x2:2 stream dual-band 2.4GHz and 5GHz concurrent connectivity with BeamFlex+
• In-room device provides integrated Wi-Fi AP and Ethernet wall switch for a wide range of devices and applications
• Multiple SSIDs, port-based VLANs support, concurrent IP-based services such as VoIP, IPTV, high-speed Internet access and in-room device connectivity
• Robust authentication options include: 802.1x, MAC-based, LDAP, RADIUS, Active Directory and authentication through an internal user database

Easy to Configure and Deploy

• Can be installed over any standard network wall outlet
• Gigabit Ethernet uplink with PoE input (802.3af/at) for easy deployment without the need for additional power outlets. Reduces the need for power cabling, switch ports and power sourcing equipment
• Powers up PoE+ devices such as IP-based VoIP phones further eliminating power cords that clutter the environment.
• Pass-through feature allows native connectivity for existing digital phones or in room network devices
• Can be deployed in standalone mode or centrally managed by the RUCKUS vSCG, SmartZone, ZoneDirector, RUCKUS Cloud Wi-Fi or RUCKUS FlexMaster systems

Perfect for hotel guest rooms and dormitories

• Sleek, inconspicuous compact form factor for best aesthetics
• Front port access eliminates unsightly cabling and disruptive furniture placement

Other Features

• Integrated dual radio 2x2 802.11ac Wav 2 Wi-Fi AP and Ethernet wall switch supporting Multi-User MIMO (MU-MIMO)
• RUCKUS patented BeamFlex+ adaptive antennas optimized for in-room performance and mobile clients
• Matched Band Coverage ensures similar Wi-Fi coverage for both 2.4 and 5 GHz client devices
• Modular options for add-on radios
• Powered by either PoE or 48VDC
• Supplies PoE power for in-room devices such as VoIP phones
• SmartCast QoS
• Multiple BSSIDs per radio with unique QoS and security policies
• WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i
• 802.1X support for RADIUS and Active Directory*
• Dynamic PSK*
• Application recognition and control*
• Mounts over a standard US and EU single gang wall jack
• RJ-45 for uplink Ethernet port
• Cable channel for preserving legacy infrastructure (e.g. PBX phones)
• SmartMesh Networking*
