The TwistPort™ Adaptor for ePMP™ 1000 AP and CSM,
ePMP™ 3000L AP and ePMP™ Force 300 CSM series, PMP
450b is compatible with all TwistPort™ Antennas.
TwistPort™ Adaptors are equipped with our original
quick-locking waveguide connector with near zero loss.
Connecting and disconnecting the radio into the TwistPort™
Adaptor is very simple and requires no tools.
Radio Connection 2x Slide-On RP-SMA
Flame Rating UL 94 HB
TECHNICAL DATA
Antenna Connection TwistPort™ - Quick Locking Waveguide Port
Materials Insert - Aluminium Alloy
Adaptor - UV stabilized and weather resistant ABS plastic
Temperature -40°C to +60°C (-40°F to +140°F)
160 km/h (100 mi/h)
0.4 Kg / 0.9 lbs – single unit
0.5 Kg / 1.1 lbs – single unit incl. package
11.2 Kg / 24.7 lbs – carton (20 units)
Retail Box: 130 × 120 × 135 mm (5.1 x 4.7 x 5.3 inch)
Carton Box: 295 x 280 x 610 mm (11.6 x 11 x 24 inch)
Wind Survival Weight
Single Unit 20 Units PERFORMANCE
Frequency Range See antenna datasheet for frequency range
Polarization Dual Linear H + V
VSWR Max 1.8
Impedance 50 Ohm
COMPATIBLE WIRELESS PLATFORMS
RF elements® any TwistPort™ Antenna
Cambium Networks™ ePMP™ 1000 AP, ePMP™ 1000 CSM, ePMP™ 3000L AP,
ePMP™ Force 300 CSM, PMP 450b, PMP 450 MicroPoP
PACKAGE CONTENTS
TwistPort™ Adaptor
TwistPort™ Adaptor Rev 05 -2023
ISO
45001
This product was produced und
