• 2 x 8-Core E5-2630v3 @ 2.40GHz
• 48GB DDR4 Ram
• 1 x Sun Oracle LSI 9361-8I SAS 12GB 8-Port PCI-E 3.0 x8 RAID Controller Card - 7085211 / 7085209

• 3 x 600GB HDD

• 2 x Sun 600W AC Power style="">
• One or two processors from the Intel Xeon processor E5-2600 v3 product family (two processors required for maximum memory and I/O configurations)
• Up to 18 cores per processor

•

• Twenty-four DIMM slots provide up to 768 GB of DDR4 ECC DIMM memory
• RDIMM options: 8 GB at DDR4-2133 and 16 GB at DDR4-2133
• Load-reduced DIMM option: 32 GB at DDR4-2133

• Four onboard auto-sensing 100/1000/10000 M Base-T Ethernet ports
• USB: six 2.0 USB ports (two front, two rear, and two internal)
• Expansion bus: Four PCIe 3.0 slots: two x16 and two x8 (one internal) slots
• Supports LP-PCIe cards including Ethernet, InfiniBand, FC, FCoE, and SAS HBAs

• Eight 2.5-inch front hot-swappable disk bays and optional DVD-RW drive
• All 2.5-inch disk bays can be populated with either HDDs or conventional SSDs
• 12 Gbps RAID HBA supporting levels: 0, 1, 5, 6, 10, 50, 60 with 1 GB of DDR3 onboard memory with flash memory backup via embedded internal SAS3 HBA PCIe Card

• VGA 2D graphics controller embedded: 8 MB
• Resolution: 1,600 x 1,200 x 16 bits @ 60 Hz via the rear HD15 VGA port (1,024 x 768 when viewed remotely via Oracle 10/100/1000 Base-T network management port
• In-band, out-of-band, and side-band network management access
• RJ45 serial management port

• Oracle Integrated Lights Out Manager (Oracle ILOM) provides:
• Remote keyboard, video, and mouse redirection
• Full remote management through command-line, IPMI, and browser interfaces
• Remote media capability (USB, DVD, CD, and ISO image)
• Advanced power management and monitoring
• Active Directory, LDAP, and RADIUS support
• Dual Oracle ILOM flash
• Direct virtual media redirection
• FIPS 140-2 mode using OpenSSL FIPS certification (#1747)

• Comprehensive fault detection and notification
• In-band, out-of-band, and side-band SNMP monitoring v1, v2c, and v3
• Syslog and SMTP alerts
• Automatically create a service request for key hardware faults with Oracle's automated service request (ASR)

• Deployment and provisioning of server bare metal
• Cloud and virtualization management
• Inventory control and patch management
• OS observability for performance monitoring and tuning
• Automated service request (ASR) generation
• Connects to Oracle Enterprise Manager Cloud Control application management
• Enables control of native Oracle Solaris, Oracle Linux, Red Hat Linux, SUSE Linux, and Microsoft Windows when running in virtual machines
