Featuring Best-In-Class Wired Connectivity9An AI PC is a connected PC, offering next-gen Wi-Fi and Bluetooth, the latest Thunderbolt™ technology, and numerous PCIe lanes.
Integrated Wi-Fi 6E + Bluetooth® 5.3 Support
Delivering supercharged Wi-Fi performance and the advancements of Bluetooth LE Audio to desktop.
Discrete Intel® Wi-Fi 710 + Bluetooth® 5.4 Support
The next stage in the evolution of wireless connectivity, Wi-Fi 7, is helping provide extreme speed, responsiveness, and reliability. Intel’s next-generation Bluetooth provides an extended range and quality for an enhanced user experience.
Intel® Connectivity Performance Suite11
Acts as your built-in IT expert by continuously optimizing your Wi-Fi connection and prioritizing your business-critical applications.
Intel® Unison™ Software12
Allows users to transfer files and photos, extend the screen, or share keyboard and mouse controls between a PC & tethered tablet or phone.
Thunderbolt™ 5 Technology
Best-in-class wired connectivity solution for gamers and creators, with up to 120 Gbps of transmit bandwidth, dual 6K video capability, and 2x more bandwidth for external SSD and other tools.
Thunderbolt™ 4 Technology
Integrated Thunderbolt™ 4 technology offers the simplest, most reliable cable solution available for connecting to a wide variety of accessories while providing outstanding performance.
Thunderbolt™ Share13
Offers users an easy, fast, and efficient way to do more with two PCs by sharing screens, keyboard, mouse, storage, and files with the speed of Thunderbolt™ technology.
Expanded I/O
Up to 20 PCIe 5.0 lanes and increased chipset PCIe 4.0 lanes.
Intel® Killer™ Networking
Delivers supercharged performance and enables seamless, immersive gameplay.
Features at a GlanceFeature
Benefit
Performance Hybrid Architecture14
Integrates two all-new core microarchitectures into a single die, prioritizing and distributing workloads to optimize performance.Intel® Thread Director4
Optimizes workloads by helping the OS scheduler intelligently distribute workloads to the optimal cores.NPU
A neural processing unit is a processor built for handling AI & machine learning tasks. Select Intel® Core™ Ultra processors include a CPU, a GPU, and an NPU.TOPS7
Trillions of operations per second. A calculated technical specification of the theoretical maximum an AI accelerator can achieve if it is 100% efficient with software and workload.Intel® Graphics Featuring Xe LPG Graphics Architecture5
A purpose-built graphics architecture optimized for lower wattage and higher performance per watt. Rich media and intelligent graphics capabilities enable amplified visual complexity, enhanced 3D performance, and faster image processing.Intel® Smart Cache
CPU memory caching method for sharing among P-cores, E-cores, and processor graphics if applicable.Intel® eXtreme Tuning Utility (Intel® XTU) with AI Assist1
A precision toolset for tuning and overclocking, featuring processor overclocking, so that new and experienced users can get more from their unlocked processors.Intel® eXtreme Memory Profile (Intel® XMP) 3.01
Allows users to overclock?compatible DDR5 memory modules to enhance the gaming features built into PCs with Intel® Core™ Ultra processors.Intel® Speed Shift Technology
Gives your CPU finer control over its frequency, allowing a fast jump up to its maximum clock speed.Intel® Turbo Boost Max Technology 3.0
Identifies the processor’s fastest cores and directs critical workloads to them as power, heat, and workload allow.Intel® Turbo Boost Technology 2.0
Accelerates processor and graphics performance for peak loads, automatically allowing processor cores to run faster than the rated operating frequency if they’re operating below power, current, and temperature specification limits.Intel® Dynamic Tuning Technology15
Power optimization tools that intelligently adapt power policies based on usage mode and temperature, with a new policy that determines and directs application resource optimization in real time.Intel® Application Optimization15
A software policy within Intel® Dynamic Tuning Technology (DTT) that determines and directs application resource optimization in real-time.Intel® Deep Learning Boost
Significantly accelerates inference performance for deep-learning workloads optimized to use VNNI.Intel® Thermal Velocity Boost
Opportunistically and automatically increases clock frequency of select Intel® Core™ Ultra Desktop processors by up to 100 MHz if the processor is at a temperature of 70°C or lower and turbo power budget is available.Intel® Adaptive Boost Technology
Intelligently boosts the processor to run faster than its rated frequency as power, heat, and workload allow.Intel® Gaussian and Neural Accelerator 3.5
Designed to process AI speech and audio applications such as neural noise cancellation while simultaneously freeing up CPU resources for overall system performance and responsiveness.Thunderbolt™ 5 Technology
Next-generation universal cable connectivity for a simple, reliable connection that provides incredible performance.Thunderbolt™ 4 Technology
An Intel-developed connectivity standard that delivers power, data, and a video signal over a single connection. The Thunderbolt™ technology certification establishes mandatory minimum requirements for cables, PCs, and accessories to help ensure greater reliability and interoperability across devices and vendors.Thunderbolt™ Share13
Unlocks ultra-fast PC-to-PC connectivity experiences.Discrete Wi-Fi 7 Support10
The next step in the evolution of wireless connectivity, helping provide extreme speed, responsiveness, and reliability.Intel® Connectivity Performance Suite11
A software solution that improves PC networking performance by creating a personalized network experience based on each user’s unique situation, automatically prioritizes high-priority traffic over lower-priority traffic.
Product InformationMfr CoreArrow LakeCompatibilityIntel Z890
Intel B860
Intel H810Level 2 Cache36MBLevel 3 Cache30MBSocket TypeLGA 1851Thermal Power125WProcessorCore Ultra 7 265KOperating Frequency3.90GHzPerformance Cores8Efficient Cores12Turbo Speed5.50GHzNumber of Threads20 Processing ThreadsProcessor Data Width64-BitTechnologyUnlocked MultiplierYesVR ReadyYesProcessor TypeDesktopMultimedia InstructionsSSE4.2
SSE4.1
AVX2Advanced TechnologiesAES New Instructions
Idle States
Thermal Monitoring Technologies
Execute Disable Bit
Intel Virtualization Technology (VT-x)
Intel 64
Enhanced Intel SpeedStep Technology
Intel Virtualization Technology for Directed I/O (VT-d)
Intel Trusted Execution Technology
Intel Turbo Boost 2.0 Technology
Intel Stable Image Platform Program (SIPP)
Intel Turbo Boost Max 3.0 Technology
Intel Thread Director
Intel Speed Shift Technology
Intel Volume Management Device (VMD)
Intel Active Management Technology (AMT)
Intel Control-Flow Enforcement Technology
Intel Total Memory Encryption
Intel OS Guard
Intel Boot Guard
Mode-based Execute Control (MBEC)
Intel Virtualization Technology with Redirect Protection (VT-rp)
Intel Gaussian & Neural Accelerator 3.0
Intel Threat Detection Technology (TDT)
Intel Standard Manageability (ISM)
Intel One-Click Recovery
Intel Hardware Shield Eligibility
Intel Secure Key
Intel Remote Platform Erase (RPE)Graphics SpecificationsGraphics SpecificationsIntel GraphicsGraphics Base Frequency300MHzGraphics Max Dynamic Frequency2.00GHzMemory SpecificationsECCNon-ECC; Non-Registered
ECC; Non-RegisteredMemory TypeDDR5-6400Integrated Memory ControllerYesMaximum Memory Supported192GBMemory Channels2Ports & ExpansionPCI Express ConfigurationsUp to 1x16+2x4, 2x8+2x4, 1x8+4x4PCI Express Revision5.0 and 4.0PCI Express Lanes24
