AMD AM5

Model #: X870E MASTER X3D ICE

MPN: X870EAMASTERXIC

UPC/EAN: 889523053089

Factory New in Box (Not Refurbished)

You are looking at a brand New Gigabyte X870E Aorus Master X3D Ice AMD AM5 ATX Motherboard.

It is factory new in box - never been used.

X3D Turbo Mode 2.0 delivers enhanced gaming and multitasking performance over the first generation. Built-in AI model and hardware circuits dynamically optimize X3D processor parameters in real-time, significantly boosting Ryzen X3D performance.

• Chipset: AMD X870E
  BIOS: 512Mb SPI Flash ROM UEFI AMI BIOS
  Manageability: PnP 1.0a, WfM 2.0, SM BIOS 2.7, ACPI 5.0, DMI 2.7
  AMD CPU Support: Ryzen
  Socket Type: AM5
  ECC: Non-ECC; Non-Registered
  Memory Type: DDR5-4800, DDR5-5200
  Memory Speeds Supported:
  9000(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8200(O.C.)/ 8000(O.C) / 7800(O.C) / 7600(O.C) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5600(O.C) / 5200 / 4800 MHz
  Memory Slots: 4 x 288pin DIMM
  Memory Channel Support: Dual Channel
  Max Memory Supported: 256GB
  Maximum Memory Supported Per Slot: 64GB
  Onboard Graphic Chipset: Requires CPU with Integrated Graphics
  M.2 Port Type: 2280, 2580
  SATA Express: 4 x M.2 Socket 3, M Key
  SATA 6Gb/s: 2
  RAID Support: RAID 0, RAID 1, RAID 5, RAID 10
  Audio Chipset: Realtek ALC1220
  Audio Channels: 7.1
  WiFi Support: Onboard WiFi
  LAN Chipset: Realtek 10Gb Ethernet
  LAN 2 Chipset: Realtek 5Gb Ethernet
  LAN Speed: 100/1000/2500/5000/10000Mbps
  Wireless LAN Chipset: Realtek Wi-Fi 7 MT7927
  Wireless Technology:
  802.11b
  802.11g
  802.11a
  WiFi 4 (802.11n)
  WiFi 5 (802.11ac)
  WiFi 6 (802.11ax)
  Bluetooth v5.4
  WiFi 7 (802.11be)
  PCI Express 4.0 x16: 1
  PCI Express 5.0 x16: 2
  LAN Ports: 1 x 10/100/1000/2500 RJ-45 LAN, 1 x 100/1000/2500/5000 RJ-45 LAN
  Audio Ports: 1 x 3.5 mm Microphone, 1 x 3.5 mm Line-Out
  Specialty Ports: 2 x WiFi Antenna Ports
  USB 3.1:
  7 x USB 3.2 (Gen 2 Type-A)
  1 x USB 3.2 (Gen 2 Type-C)
  1 x USB 3.2 (Gen 2x2 Type-C)
  2 x USB4 (Type-C 40 Gb/s)
  Video Connectors: 1 x HDMI 2.1
  Digital Audio: 1 x Optical
  Headers: 4 x System Fan Header, 1 x Water Pump Header, 2 x CPU Fan Header
  USB:
  2 x USB 2.0 Headers (4 Ports)
  2 x USB 3.2 Gen 1 Type-A Headers (4 Ports)
  1 x USB 3.2 Gen 2x2 Type-C Header (1 Port)
  Other I/O: 4 x Addressable LED Headers
  Power Connectors: 1 x 24-pin ATX Connector, 3 x 8-Pin +12 V Connector
  ATX Connector: 24-pin ATX Power Connector
  Depth: 12.00 in. (304.80 mm)
  Width: 9.61 in. (244.00 mm)
  Form Factor: ATX
  What's in the Box
  Motherboard
• Manual
• Antenna
• 2x SATA Cables
• DDR Wind Blade
• Fan Power Extension Cable
• Noise Detection Cable
• 2x Thermistor Cables
• 2x Cable Ties
• G Connector
