If you have any problems with the product please contact us immediately, we will resolve the problem quickly and will help you asap! Please don't leave OPEN CASE on or leave Negative response before contacting us. ThanksNIB Cisco Meraki CW9164I-MR High-Performance Cloud-Managed 802.11ax Unclaimed WANEW Cisco Meraki CW9164I-MR High-Performance Cloud-Managed 802.11ax Unclaimed Access PointOverview
The Cisco CW9164I-MR is a high-performance, Wi-Fi 6 (802.11ax) access point designed for indoor use in environments with high-density wireless demands. It provides robust security, excellent coverage, and the ability to manage numerous simultaneous connections, making it ideal for enterprise environments that require reliable and secure wireless class="tab-switch__content" 0, 0);font-family:"Open Sans", Arial, Helvetica, 255, 255)">
- Form Factor: Indoor wall-mounted access point
- Dimensions: 8.9 inches (W) x 8.9 inches (L) x 1.4 inches (H) (226.1 mm x 226.1 mm x 35.5 mm)
- Weight: Approximately 1.5 kg (3.3 lbs)
- Wi-Fi Standard: Wi-Fi 6 (802.11ax) support for faster speeds and improved network efficiency
- Radio Frequency Bands:
- Dual-band: 2.4 GHz and 5 GHz
- 6 GHz: Supported in 6E variants
- MIMO (Multiple Input, Multiple Output): 4x4 MU-MIMO (Multi-User, Multiple-Input, Multiple-Output) for better simultaneous connections and higher throughput
- Max Data Rate:
- Up to 5.4 Gbps total throughput across both bands (2.4 GHz and 5 GHz combined)
- Channel Width: Supports 20, 40, 80, and 160 MHz channel widths for flexible bandwidth configurations
- Antenna: Internal antennas optimized for high-density environments
- Ethernet Ports:
- 1 x Gigabit Ethernet (1G) port for standard network connectivity
- 1 x 2.5G Ethernet port for higher-speed uplinks and power delivery (PoE+)
- Power over Ethernet (PoE):
- PoE+ (IEEE 802.3at) support for power delivery via Ethernet, eliminating the need for separate power cables
- WPA3, WPA2, and WPA support for enhanced wireless security
- 802.1X for network access control
- Integrated VPN support and intrusion detection/prevention features for secure wireless communications
- Cisco CleanAir: Built-in interference detection and mitigation
- Cisco ClientLink: Optimizes client performance across all devices on the network
- Cisco Band Select: Automatically selects the best band (2.4 GHz or 5 GHz) for client devices
- User Capacity: Supports hundreds of simultaneous users per access point, making it ideal for high-density environments such as large office spaces, educational institutions, and public venues
- Advanced QoS: Quality of Service (QoS) features for traffic prioritization, ensuring high performance for critical applications such as voice and video
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Non-Operating Temperature: -40°C to 70°C (-40°F to 158°F)
- Operating Humidity: 10% to 90% non-condensing
- Storage Humidity: 5% to 95% non-condensing
- Mounting Options: Designed for easy wall-mount installation, perfect for space-constrained areas
- Power and Energy
- Power Supply:
- Powered by PoE+ (Power over Ethernet) for flexibility and ease of installation
- Optional external power adapter for non-PoE environments (sold separately)
- Power Consumption: Approximately 15W (depending on usage and network conditions)
- Software and Management
- Managed via Cisco DNA Center for easy network management and automation
- Supports Cisco Meraki Cloud Management for cloud-based configuration and monitoring
- Cisco Mobility Express: Standalone deployment option for small to medium-sized environments without a controller
- Additional Features
- Mesh Networking: Supports wireless mesh networking for extended coverage without additional cabling
- Cisco Umbrella Integration: Cloud security integration for advanced threat protection and policy enforcement
- Condition : New
