8x10 GE SFP+/SFP - C4KX-NM-8SFP+

Management Port

10/100/1000 Base-T

USB Port

Type A (storage and boot) up-to 4 GB

Dual Power Supply

Yes

Field Replaceable Fans

Yes (5 fans)

Fan Redundancy

No performance impact with single fan failure

System Throughput

Up to 800 Gbps

IPv4 Routing in Hardware

Up to 250 Mpps

IPv6 Routing in Hardware

Up to 125 Mpps

L2 Bridging in Hardware

Up to 250 Mpps

Media Access Control (MAC) Entries

55K

Forwarding Entries

32x10 GE Port Base SKU: IPv4: 256K, IPv6: 128K

Flexible Netflow Entries

128K

Switched Port Analyzer (SPAN), Remote Switched Port Analyzer (RSPAN)

8 line rate offerirectional sessions (ingress and egress)

Total VLANs

4094

Total Switched Virtual Interfaces (SVIs)

4094

IGMP groups

32K

Multicast routes

32x10 GE Port Base SKU: IPv4: 32K, IPv6: 32K

Dynamic Host Configuration Protocol (DHCP) Snooping Entries

12K (DHCP snooping bindings)

ARP Entries

47K

Spanning Tree Protocol Instances

10K

Jumbo Frame Support for Bridged and Routed Packets

Up to 9216 bytes

High Availability Solution

Virtual Switching System (VSS)

Number of stackable switches in VSS

Up to 2

VSS Throughput

Up to 1.6 Tbps

Virtual Switch Link

1GE or 10GE

Max number of Virtual Switch Links

8

In-Service Software Upgrade

Across the switches

Nonstop Forwarding with Stateful Switchover

Across the switches

Onboard Memory (SRAM DDR-II)

4 GB

Port Buffers

32-MB Shared Memory

CPU

Dual Core 1.5 GHz

NVRAM

2 GB

Optional External Memory (SDCard)

2 GB

Port Queues

8 Queues/Port

CPU Queues

64

QoS Entries

128K (64K ingress and 64K in egress) Shared with ACL

Aggregate Rate-Limiting

Ingress port or VLAN and egress VLAN or Layer 3 port

Rate-Limiting Level Types

Committed Information Rate (CIR), Peak Information Rate (PIR)

Aggregate Traffic Rate-Limiting Policers (1K=1024)

16K

Flow-Based Rate-Limiting Method; Number of Rates

Supported using flow-records in the classification criteria and policing action

Qos Policy Enforcement

Per Port or Per Vlan or Per Port, Per VLAN Granularity

Class of Service (CoS)

Yes

Differentiated Services Code Point (DSCP)

Yes

Port Security

Yes

IEEE 802.1x and 802.1x Extensions

Yes

VLAN, Router, and Port ACLs

Yes

Security ACL Entries (1K=1024)

128K (64K ingress and 64K in egress) Shared with QoS

Unicast Reverse Path Forwarding (uRPF) Check in Hardware

Yes

CPU Rate Limiters (DoS Protection) Includes Control Plane Policing

Yes

Private VLANs

Yes

Micro Flow Policer

Yes. Supported using flow records in the class-map

CPU HW Rate Limiters by Packet Per Second (pps) and Bit Rate Policers (bps)

Supported in hardware control-plane policing (CoPP)

Control Plane Policing (CoPP) for Multicast

Yes

ACL Labels

Yes

Cisco IOS Software, IOS-XE Software, Catalyst 4500 L3 Switch Software (cat4500e-UNIVERSALK9-M), Version 03.06.04.E RELEASE SOFTWARE (fc2)
Technical Support:
Copyright (c) 1986-2016 by Cisco Systems, Inc.
Compiled Fri 12-Feb-16 22:40 by prod_rel_teamCisco IOS-XE software, Copyright (c) 2005-2015 by cisco Systems, Inc.
All rights reserved. Certain components of Cisco IOS-XE software are
licensed under the GNU General Public License ("GPL") Version 2.0. The
software code licensed under GPL Version 2.0 is free software that comes
with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such
GPL code under the terms of GPL Version 2.0.
() For more details, see the
documentation or "License Notice" file accompanying the IOS-XE software,
or the applicable URL provided on the flyer accompanying the IOS-XE
software.ROM: 15.0(1r)SG12
Switch uptime is 13 minutes
System returned to ROM by power-on
Running default software
Jawa Revision 3, Winter Revision 0x0.0x41Last reload reason: power-onThis product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.License Information for 'WS-C4500X-32'
License Level: entservices Type: Permanent
Next reboot license Level: entservicescisco WS-C4500X-32 (MPC8572) processor (revision 9) with 4194304K bytes of physical memory.
Processor board ID JAE2017017V
MPC8572 CPU at 1.5GHz, Cisco Catalyst 4500X
Last reset from PowerUp
1 Virtual Ethernet interface
40 Ten Gigabit Ethernet interfaces
511K bytes of non-volatile configuration memory.Configuration register is 0x2101Switch#show inventory
NAME: "Switch System", DESCR: "Cisco Systems, Inc. WS-C4500X-32 2 slot switch "
PID: , VID: , SN: JAE2017017VNAME: "Supervisor(slot 1)", DESCR: "4500X-32 10GE (SFP+)"
PID: WS-C4500X-32 , VID: V06 , SN: JAE2017017VNAME: "TenGigabitEthernet1/5", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM200844Y8NAME: "TenGigabitEthernet1/6", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM200846EDNAME: "TenGigabitEthernet1/7", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM201644YVNAME: "TenGigabitEthernet1/8", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM201644YANAME: "TenGigabitEthernet1/9", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM201644YKNAME: "TenGigabitEthernet1/10", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM201644YUNAME: "TenGigabitEthernet1/11", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM201645DHNAME: "TenGigabitEthernet1/12", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM201644YFNAME: "TenGigabitEthernet1/13", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM201644YBNAME: "TenGigabitEthernet1/14", DESCR: "1000BaseT"
PID: Unspecified , VID: , SN: AGM201644YENAME: "Linecard(slot 2)", DESCR: "10GE SFP+"
PID: C4KX-NM-8 , VID: V04 , SN: JAE202005LMNAME: "Power Supply 1", DESCR: "Power Supply ( AC 750W )"
PID: C4KX-PWR-750AC-R , VID: V01 , SN: ART2208X049NAME: "Power Supply 2", DESCR: "Power Supply ( AC 750W )"
PID: C4KX-PWR-750AC-R , VID: V01 , SN: ART2208X08GSwitch#show license summary
Index 0 Feature: entservices
Period left: Life time
License Type: Permanent
License State: Active, In Use
License Count: Non-Counted
License Priority: Medium
Index 1 Feature: ipbase
Period left: 8 weeks 4 days
License Type: Evaluation
License State: Active, Not in Use, EULA not accepted
License Count: Non-Counted
License Priority: None
Index 2 Feature: lanbase
Period left: 1513 weeks 1 day
License State: Active, Not in Use, EULA not accepted
License Count: Non-Counted
Index 3 Feature: internal_service
Period left: 0 secondsSwitch#show environment
no temperature alarmsModule Sensor Temperature XPP 27C (85C,90C,95C) ok
1 IFE 31C (85C,90C,95C) ok
1 CPU 36C (85C,90C,95C) ok
1 FPGA 37C (85C,90C,95C) ok
1 Air outlet 25C (70C,75C,80C) ok
1 Air inlet 18C (60C,65C,70C) ok
2 Air inlet 16C (60C,65C,70C) ok
2 Air outlet 22C (70C,75C,80C) okPower Fan Inline
Supply Model No Type Status Sensor Status
------ ---------------- --------- ----------- ------- -------
PS1 PWR-C4KX-750AC-R AC 750W good good n.a.
PS2 PWR-C4KX-750AC-R AC 750W good good n.a.Power supplies needed by system : 1
Power supplies currently available : 2Chassis Type : WS-C4500X-32Power consumed by backplane : 0 WattsSwitch Bandwidth Utilization : 0%Supervisor Led Color : GreenModule 1 Status Led Color : Green
Module 2 Status Led Color : GreenBeacon Led Status : off
Fan trays needed by system : 4
Fan trays currently available : 5
Chassis fan tray direction : FrontToBackFantray 1 : dir : FrontToBack status : Good
Fantray 2 : dir : FrontToBack status : Good
Fantray 3 : dir : FrontToBack status : Good
Fantray 4 : dir : FrontToBack status : Good
Fantray 5 : dir : FrontToBack status : GoodFantray removal timeout : 180Power consumed by Fantray : 90 Watts
