Product InformationMfr X870CPU SupportAMD CPU SupportRyzenSocket TypeAM5Memory SpecificationsECCNon-ECC; Non-RegisteredMemory TypeDDR5-4800
DDR5-5200
DDR5-5400
DDR5-5600
DDR5-5000Memory Speeds Supported8400+(OC)/ 8200+(OC)/ 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHzMemory Slots4 x 288pin DIMMMemory Channel SupportDual ChannelMax Memory Supported256GBMaximum Memory Supported Per Slot64GBVideo SpecificationsOnboard Graphic ChipsetRequires CPU with Integrated GraphicsMulti-GPU Support2-Way CrossFireStorage SpecificationsM.2 Port Type2260
2280
22110SATA Express1 x M.2 Socket 3
E Key
4 x M.2 Socket 3
M KeyRAID SupportRAID 0
RAID 1
RAID 10Audio SpecificationsAudio ChipsetRealtek ALC4080Audio Channels7.1NetworkingWiFi SupportM.2 SlotLAN ChipsetRealtek 8126-CGLAN Speed100/1000/2500/5000MbpsWireless Technology802.11b
802.11g
802.11a
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
Bluetooth v5.4
WiFi 7 (802.11be)Expansion SlotsPCI Express 4.0 x161PCI Express 5.0 x161PCI Express 3.0 x161Back Panel PortsLAN Ports1 x 100/1000/2500/5000 RJ-45 LANAudio Ports1 x 3.5 mm Microphone
1 x 3.5 mm Line-OutSpecialty Ports2 x WiFi Antenna PortsUSB 2.04 x USB 2.0 (Type-A)USB 3.11 x USB 3.2 (Gen 2 Type-C)
2 x USB 3.2 (Gen 2 Type-A)
3 x USB 3.2 (Gen 1 Type-A)
2 x USB4 (Type-C 40 Gb/s)Video Connectors1 x HDMI 2.1Digital Audio1 x OpticalInternal I/O & ConnectorsHeaders1 x CPU Fan Header
6 x System Fan HeaderOther I/O3 x RGB LED connectorsPowerPower Connectors1 x 24-pin ATX Connector
2 x 8-pin +12 V Connector
1 x 8-pin PCIe Power ConnectorATX Connector24-pin ATX Power ConnectorPhysical SpecificationsDepth12.00 in. (305.00 mm)Width9.60 in. (243.84 mm)Form FactorATXWarrantyParts3 YearsLabor3 YearsPackage ContentsWhat's in the BoxMotherboard, Manual, 2x SATA Cables, EZ M.2 Clip, Clip Remover, M.2 Screw, USB Drive, Cable Stickers, Antenna, 1 to 3 EZ Conn-Cable, EZ Front Panel Cable
