CPU

• Supports 3rd Gen Intel® Core™ i7 / Core™ i5 / Core™ i3 / Pentium® / Celeron® processors for LGA 1155 socket
Please refer to CPU Support for compatible CPU; the above description is for reference only.

Chipset

• Intel® B75 Chipset

Memory

• Memory speed support up to 1333MHz are provided on 2nd Gen Intel® Core™ i7 / Core™ i5 / Core™ i3 / Pentium® / Celeron® processors (codename Sandy Bridge, 32nm)
• Memory speed support up to 1600MHz are provided on 3rd Gen Intel® Core™ i7 / Core™ i5 / Core™ i3 / Pentium® / Celeron® processors (codename Ivy Bridge, 22nm)
Note: DDR3 1600 MHz memory support vary based on the Intel® Ivy Bridge processors use
• Memory speed support beyond 1600MHz are provided on some 3rd Generation Intel Core i7-3770K CPUs. This will vary based on quality of CPU.
• Support up to 32GB of system memory*
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
• Support Dual-Channel mode, two DIMMs per channel

Slots

• 1 x PCIe 3.0 x16 slots
- PCI_E2 supports up to PCIe 3.0 x16 speed
• 1 x PCIe 2.0 x16 slot
- PCI_E4 supports up to PCIe 2.0 x4 speed
• 2 x PCIe 2.0 x1 slots
• 3 x PCI slots

On-Board SATA

• SATAIII controller integrated in Intel® B75 chipset
- Up to 6Gb/s transfer speed.
- Supports one SATAIII ports (SATA1) by B75
• SATAII controller integrated in Intel® B75 chipset
- Up to 3Gb/s transfer speed.
- Supports five SATAII ports (SATA2~6) by B75

USB 3.0

• 2 x USB 3.0 rear IO ports by Intel® B75
• 1 x USB 3.0 onboard connector by Intel® B75

Audio

• Chipset integrated by Realtek® ALC892
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec

LAN

• Supports one PCI Express LAN 10/100/1000 Fast Ethernet by Realtek® 8111E

Internal I/O Connectors

- ATX 24-Pin power connector
- 8-pin ATX 12V power connector
- CPU x 1 / System x 4 FAN connectors
- 1 x Clear CMOS jumper
- 5 x Serial ATAII connectors
- 1 x Serial ATAIII connector
- 2 x USB 2.0 connectors
- 1 x USB 3.0 connector
- 1 x Serial port connector
- 1 x Parallel port connector
- 1 x Trusted Platform Module (TPM) header
- 1 x Front Panel Audio connector
- 1 x Front Panel connector
- 1 x Chassis Intrusion connector
- 1 x Voice Genie connector (optional)

Back Panel I/O Ports

- 1 x PS/2 keyboard/ mouse port
- 4 x USB 2.0 ports
- 2 x USB 3.0 ports
- 1 x RJ45 LAN Jack
- 1 x 6 in 1 audio jack
- 1 x HDMI® port with max. resolution up to 1920x1200 at 60Hz
- 1 x DVI-D port with max. resolution up to 1920x1200 at 60Hz
- 1 x VGA port with max. resolution up to 2048x1536 at 75Hz

BIOS

• The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.
• The motherboard provides a Desktop Management Interface(DMI) function which records your motherboard specifications.

Dimension

• 30.5cm(L) x 24.5cm(W) ATX Form Factor

Mounting

• 9 mounting holes.
