GMKtec M5 Ultra Mini Desktop PC Ryzen 7 7730U 32GB Windows 11 ProSpecifications
M5 Ultra
M5S
Model GMKtec NucBox M5 Ultra GMKtec NucBox M5S
CPU Model AMD Ryzen™ 7 7730U AMD Ryzen™ 3 5400U
CPU 8 Cores / 16 Threads
Base Clock: 2.0GHz
Max Boost Clock: Up to 4.5GHz
4MB L2 Cache / 16MB L3 Cache 4 Cores / 8 Threads
Base Clock: 2.6GHz
Max Boost Clock: Up to 4.0GHz
2MB L2 Cache / 8MB L3 Cache
Architecture / Process AMD Ryzen™ 7000 Series
Zen 3 Architecture
TSMC 7nm FinFET AMD Ryzen™ 5000 Series
TSMC 7nm FinFET
Performance Modes Silent Mode: 10W
Balanced Mode: 15W
Performance Mode: 35W
Peak Power: 35W Silent Mode: 10W
Balanced Mode: 15W
Performance Mode: 25W
Peak Power: 35W
GPU AMD Radeon™ Graphics
8 GPU Cores, up to 2000MHz AMD Radeon™ Graphics
6 GPU Cores, up to 1600MHz
Memory (RAM) 2× SO-DIMM Slots
DDR4-3200
16GB / 32GB Configurations
Dual-Channel Support 2× SO-DIMM Slots
DDR4-3200
16GB / 32GB Configurations
Dual-Channel Support
Maximum Memory Up to 64GB (32GB×2) Up to 64GB (32GB×2)
Storage 2× M.2 2280 SSD Slots
512GB PCIe 3.0 ×4 SSD Pre-installed 2× M.2 2280 SSD Slots
512GB PCIe 3.0 ×4 SSD Pre-installed
Storage Interface Slot 1: SATA or PCIe 3.0 ×4
Slot 2: PCIe 3.0 ×4 Slot 1: SATA or PCIe 3.0 ×4
Slot 2: PCIe 3.0 ×4
Storage Expansion Up to 8TB per SSD
Up to 16TB total storage Up to 8TB per SSD
Up to 16TB total storage
Graphics Output Triple Display Output
HDMI + DisplayPort + USB-C
Up to 8K@60Hz via DisplayPort Triple Display Output
HDMI + DisplayPort + USB-C
Up to 8K@60Hz via DisplayPort
Wi-Fi Wi-Fi 6E
AMD RZ616
Up to 2.4Gbps Wi-Fi 6E
AMD RZ616
Up to 2.4Gbps
Bluetooth Bluetooth 5.2 Bluetooth 5.2
Ethernet Dual 2.5G RJ45 LAN
Realtek RTL8125 Dual 2.5G RJ45 LAN
Realtek RTL8125
Power DC 19V / 3.42A
Built-in Coin Cell Battery DC 19V / 3.42A
Built-in Coin Cell Battery
USB-A Ports 2× USB 3.2 Gen 2 (10Gbps)
2× USB 2.0 (480Mbps) 2× USB 3.2 Gen 2 (10Gbps)
2× USB 2.0 (480Mbps)
USB-C Port 1× USB-C
USB 3.2 Gen 2, 10Gbps
100W PD Input
DisplayPort 1.4
Up to 4K@60Hz 1× USB-C
USB 3.2 Gen 2, 10Gbps
100W PD Input
DisplayPort Video Output
Up to 4K@60Hz
HDMI 1× HDMI 2.0, up to 4K@60Hz 1× HDMI 2.0, up to 4K@60Hz
DisplayPort 1× DisplayPort 1.4
Up to 8K@60Hz 1× DisplayPort 1.4
Up to 8K@60Hz
Audio 1× 3.5mm CTIA Audio Jack 1× 3.5mm CTIA Audio Jack
Other Ports 1× DC IN (5.5/2.5mm)
1× Reset / Clear CMOS Button
1× Power Button 1× DC IN (5.5/2.5mm)
1× Reset / Clear CMOS Button
1× Power Button
Cooling System Dual-Fan Cooling Design Copper Heat Pipe + Dual-Fan Cooling
Operating System Windows 11 Pro Windows 11 Pro
Chassis Dimensions 128.8 × 127 × 47.8 mm 128.8 × 127 × 47.8 mm
Weight 528g Approximately 528g
Packaging List User Manual
Warranty Card
Power Adapter
VESA Mount Bracket
HDMI Cable
