Model: AFC1212DE

DELL P/N: D8794

Lead wire: 4 wires (supports pwm)

Voltage: DC 12V

Current: 1.60A

Speed: 4000RPM

Air volume: 154.5CFM

Noise: 45.4dB-A

Bearing: high precision double ball bearing

Fan frame: injection molding, PBT + 30% glass fiber VO grade flame retardant

Wind blade: injection molding, PBT + 30% glass fiber + VO grade flame retardant.

Fan rotation: counterclockwise from the direction of the fan blade

Operating temperature: -10 degrees Celsius to +70 degrees Celsius

Storage temperature: -40 degrees Celsius to +70 degrees Celsius

Power range: plus or minus 15% of rated power

Insulation resistance: greater than 500 megohms

Withstand voltage: sink current 0.5mA 500V / 1 minute

Working life: 80000 hours when the ambient temperature is 25 degrees

Scope: DELL Precision 390 workstation CPU cooling mining machine and other equipment
