GeneralEnergy SavingGreenPower UPS™ Bypass TechnologyEnergy Star CertifiedYesUPS TopologyLine InteractiveBatteryBattery Quantity2Battery Size6 V / 8 AhBattery TypeSealed Lead-Acid BatteryHot SwappableYesReplacement Battery CartridgeRB0690X2Replacement Battery Cartridge Quantity1Runtime at Full Load1.5 minRuntime at Half Load10.5 minTypical Recharge Time8 HoursUser Replaceable BatteryYesInputAdjustable Voltage Range97 – 144 VACCircuit Breaker15 ACord Length10 ft (3.0 m)Input Frequency Range57 Hz – 63 HzInput Plug TypeNEMA 5-15PInput Voltage Range88 VAC – 144 VACNominal Input Voltage120 VACPlug StyleRight Angle – 45° OffsetOutputAutomatic Voltage RegulationSingle BoostOn AC WaveFormSine WaveOn Battery Frequency60 Hz ± 1%On Battery Voltage120 VAC ± 10%On Battery WaveformSine WaveOutlet Type6 – NEMA 5-15ROutlets – Battery & Surge Protected4Outlets – Surge-Only Protected2Outlets – Total6Output Power Factor0.57Overload ProtectionInternal Circuitry Limiting
Circuit Breaker ProtectedTypical Transfer Time8 msUSB Charge PortNoVA700 VAWatts400 WSurge Protection & FilteringEMI/RFI FiltrationYesNetwork Protection RJ451-in / 1-Out (10/100/1000)Surge Suppression (Joules)1150 JManagement & CommunicationsAudible AlarmsBattery Mode
Low Battery
Overload
FaultHID Compliant USB PortYesLCDMultifunction LCDLED IndicatorsPower On
Wiring FaultManagement CableUSB CableSNMP / HTTP Remote MonitoringYes – with optional RMCARD205Serial Port1 Dry ContactSoftware (Free Download)PowerPanel® BusinessPhysicalColorBlackForm FactorRackmountMaterial of ConstructionMetalRack Height1UDimensionsPhysical Dimensions – (WxHxD) (cm)43.31 x 4.39 x 22.96 (cm)Physical Dimensions – (WxHxD) (in)17.05 x 1.73 x 9.04 (in)Physical Dimensions – (WxHxD) (mm)433 x 44 x 230 (mm)Physical Weight (kg)8.3Physical Weight (lb)18.3Dimensions – ShippingShipping – Weight (kg)9.01Shipping – Weight (lb)20.87Shipping Dimensions – (WxHxD) (cm)53.01 x 15.49 x 27.99 (cm)Shipping Dimensions – (WxHxD) (in)20.87 x 6.1 x 11.02 (in)Shipping Dimensions – (WxHxD) (mm)530.1 x 154.94 x 279.91 (mm)EnvironmentalOperating Elevation0 – 10000 ft (0 – 3048 m)Operating Relative Humidity0 – 95 % (non-condensing)Operating Temperature32 – 104 °F (0 – 40 °C)Storage Elevation0 – 50000 ft (0 – 15239 m)Storage Relative Humidity0 – 95% (non-condensing)Storage Temperature5 – 113 °F (-15 – 45 °C)CertificationsEnvironmentalRoHS CompliantSafetyUL1778
CSA C22.2 No. 107.3
FCC Class B
DOEWarrantyCEG Amount$300000Connected Equipment GuaranteeLifetimeExtended Warranty OptionWEXT5YR-U2AProduct Warranty3 Year Limited Warranty
