Cisco Gigabit Ethernet SX Mini-GBIC SFP Transceiver 1 x 1000Base-SX Model MGBSX1
BrandCisco Systems, IncPart NumberMGBSX1Compatible BrandSR2024 - 24-Port 10/100/1000 Gigabit Switch
SR224G - 24-Port 10/100 + 1-Port Gigabit Switch + 1 MiniGBIC
SRW2016 - 16-Port 10/100/1000 Gigabit Switch with WebView
SRW2024 - 24-Port 10/100/1000 Gigabit Switch with WebView
SRW224 - 24-port 10/100 + 2-Port Gigabit Switch with WebViewDevice TypeTransceiverForm FactorSFPNetwork MediaMedia Type Supported:
Optical FiberFiber Mode Supported:
Multi-modeMaximum Distance Supported:
0.55 kmWavelengthTransmitter Spec: Power: -9.5 to -4 dBm
Reciever Spec: Sensitivity: -20 to -17dBm
Input Power: -20 to -17 dBm
Stress Sensitivity: 50/125 um: -13.5dBm, 62.5/125 um: -12.5dBm
Wavelength: 850 nm (850nm TYP., 830-860nm) MMF
Modular Bandwidth for MMF:62.5/125um MMF at 160 MHz/km, up to 220m
62.5/125um MMF at 200 MHz/km, up to 275m
50/125um MMF at 400 MHz/km, up to 500m
50/125um MMF at 500 MHz/km, up to 550mFiber CableMulti-mode Optical FiberProtocolsTCP/IPPortsTotal Number of Ports:
1Connector Type:
LCInterfaces/Ports Details:
1 x LC 1000Base-SXMax Distance500mTransfer Rate1 GbpsFeatureAverage output power: -9.5 dBm to -4 dBmReceiver sensitivity: -20 dBm (typ)Receiver overload: -0 dBmCompliance:
FCC Part 15 Class B
EN55022 Class B (CISPR 22B)
VCCI Class BSafety:
FDA 21 CFR 1040.10 and 1040.11
EN60950, EN (IEC) 60825-1, 2Compatibility:
SR2024 - 24-Port 10/100/1000 Gigabit Switch
SR224G - 24-Port 10/100 + 1-Port Gigabit Switch + 1 MiniGBIC
SRW2016 - 16-Port 10/100/1000 Gigabit Switch with WebView
SRW2024 - 24-Port 10/100/1000 Gigabit Switch with WebView
SRW224 - 24-port 10/100 + 2-Port Gigabit Switch with WebViewPackage ContentsCisco SFP transceiver
Quick installation guide
