Blackmagic Design DeckLink IP HD MFR: BDLKIPBIP/HD
The Blackmagic Design DeckLink IP HD is a PCIe playback and monitoring card designed for 2110 IP-based broadcast systems. It provides capture and playback of 10-bit uncompressed HD video up to 1080p60, with two input and two output video channels over a single 10G Ethernet connection with embedded audio.
Key Features
- PCIe 4-lane, Generation 2 interface
- Designed for SMPTE ST 2110 IP broadcast systems
- 10-bit uncompressed video up to 1080p60
- Two input and two output video channels over a single RJ45 10G Ethernet connection
- Embedded 16-channel audio over LAN
- Supports SD and HD video formats up to 1080p60
- Supports 8/10/12-bit 4:4:4 RGB and 8/10-bit 4:2:2 YUV formats
- PTP synchronization using a common clock
- Built-in video firewall isolates the Ethernet port from non-video and non-audio traffic
- NMOS support for IS-04 discovery and registration and IS-05 connection management
- Compatible with macOS, Windows and Linux
- Supports professional applications including DaVinci Resolve, Avid Media Composer, Final Cut Pro and Adobe Premiere
- Blackmagic Media Express and Blackmagic Disk Speed Test included
- Developer SDK available for Mac, Windows and Linux
Technical Specifications System Connection PCIe x4 Input / Output 1 x RJ45 10G Ethernet Audio Inputs None Embedded Audio LAN (RJ45): 16-channel Video Standard Compliance SMPTE ST-2082 / ST-2100 / ST-2110 HDR Support No Input Video RJ45, 8/10/12-bit 4:4:4 RGB and 8/10-bit 4:2:2 YUV.
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps.
1080i at 50/59.94/60 fps.
720p at 50/59.94/60 fps.
576i / 625 lines at 50 fps.
480i / 525 lines at 59.94 fps. Output Video RJ45, 8/10/12-bit 4:4:4 RGB and 8/10-bit 4:2:2 YUV.
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps.
1080i at 50/59.94/60 fps.
720p at 50/59.94/60 fps.
576i / 625 lines at 50 fps.
480i / 525 lines at 59.94 fps. Operating System Compatibility macOS 12 to 13 or later
Windows 10 (64-bit only)
Windows 11
Linux Power Consumption 10 W Operating Temperature 32 to 104°F / 0 to 40°C Storage Temperature -4 to 113°F / -20 to 45°C Operating Humidity 0 to 90% Dimensions 7.2" / 18.3 cm Weight 3.7 oz / 104.9 g In The Box
- Blackmagic Design DeckLink IP HD
- Low Profile Slot Bracket
- Welcome Wallet with QR Code
- Limited 3-Year Manufacturer Warranty
The DeckLink IP HD is designed for professional HD capture and playback workflows within 2110 IP broadcast systems, including broadcast, streaming and custom broadcast automation applications.
