Features

• Quickly adds WiFi 6 and Bluetooth 5.2 wireless connectivity through an available PCI Express slot to server or desktop systems
• Wi-Fi 6 provides Gigabit wireless speed and dramatically improves wireless coverage at home and work environments
• Supports the new WPA3 security feature, enabling next-generation authentication and military-grade encryption
• Supports speeds up to 2.4G Mbps on 5 GHz or 574 Mbps on 2.4 GHz dual band data rate
• MIMO technology effectively improves signal gain when multiple users are sending and receiving at the same time
• Delivers 80MHz to 160MHz, double throughput, ultra-low latency, and uninterrupted connectivity
• Works with all current Wi-Fi routers and backward compatible with 802.11a/b/g/n/ac Wi-Fi standards
• Bluetooth 5 provide 4 times the coverge range over Bluetooth 4.2 and enhances data broadcasting, enabling seamless services such as location-based services plus simpler pairing of Bluetooth devices.Note: Bluetooth operation requires connecting the USB cable between the adapter card and your motherboard's 4pin USB header
• Supports all PCIe standards, PCIe x1 bus connector installs into any size PCI Express slot
• Fits both standard and low profile system chassis with the included full height and spare low profile brackets

• Chipset: Intel AX200KILLER 1650i
• Complies with PCI Express 2.1 specification
• Bus connector: x1 PCI Express
• Connector Type: 2 x 5dBi un-fixed and USB 4-Pin header (Bluetooth 5 operation)
• Industry Standards: IEEE802.11.ax, IEEE802.11.ac, IEEE802.11.n, IEEE802.11.b, IEEE802.11.g, IEEE802.11.a
• Bluetooth: Bluetooth 5.2
• Security Methods: WPA and WPA2 Personal and Enterprise, WPA3
• Authentication Protocols: 802.1X EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0-MSCHAPv2(EAP-SIM, EAP-AKA, EAP-AKA)
• Encryption: 64-bit and 128-bit WEP, TKIP, 128-bit AES-CCMP, 256-bit AES-GCMP
• Data Rates: 5G up to 2.4G (802.11ax 160MHz) / 2.4G up to 574M
• Product:
  • Dimensions: 2.83" (L) x 4.72" (W) x 0.71" (H)
  • Weight: 0.10 lbs
  • Color: Black
  • Connectors: 2 x 5dBi un-fixed & USB 4-Pin header
• Environmental conditions:
  • Operating temperature: 32 to 140 degrees F
  • Storage temperature: -14 to 158 degrees F
  • Relative humidity: 5% to 90% RH FCC, CE, RoHS
  Package contents
  • WiFi 6 Dual Band Ethernet PCIe Card - AX3000
  • Spare low profile bracket
  • 2*5dbi Antennas
