Which antenna configuration should I choose?
- 4x12dBi Directional Antenna:
Designed for point-to-point applications. The directional design focuses signal in a specific direction,
suitable for connecting two distant locations (e.g., building-to-building, farm-to-farm). - 6x7dBi Omni Antenna: 6-antenna omni-directional configuration. While each antenna has slightly lower gain (7dBi vs 8dBi),
the additional two antennas improve MU-MIMO performance, which helps when many devices connect simultaneously.
Suitable for high-density areas such as RV parks, event spaces, or public squares. All three configurations share the same
AX3000 WiFi 6 platform, IP67 weatherproof enclosure, PoE support, and outdoor-rated components

4x 12dBi Dir Antennas(Built-in), Long Range/PtP up to 3KM

Built to Withstand the Elements- IP67-rated waterproof housing that ensures continued operation
on harsh outdoor environments or in climates of extreme cold, heat or continuous moisture.
With lightning protection and a weatherproof design, you can trust that your connection will remain stable and secure.
Note: The PoE part of the router is not waterproof.

Enjoy True WiFi 6 Speed - TExperience the future of wireless connectivity with next-generation WiFi 6 technology,
complying with IEEE 802.11 ac/a/b/g/n standards. Enjoy dual-band speeds of up to 5GHz 2402Mbps and 2.4GHz 573Mbps,
perfect for seamless HD video streaming, online gaming, and more, even in outdoor environments.

Convenient PoE Power Supply - This WiFi6 router supports both 802.3AF/AT active PoE and passive PoE,
allowing you to transfer data and power the device with a single Ethernet cable. This feature makes it easy to install the
router in outdoor locations where power outlets are scarce. Please note that the PoE converter is not waterproof,
and we recommend using CAT5E or above cables with a maximum length of 100m/328ft.

Seamless WiFi Coverage - Built-in 4x12dBi directional antennas and high-power amplifiers provide exceptional WiFi coverage and
penetration. With Everything Mesh technology, you can easily connect multiple devices and expand your WiFi network,
eliminating dead zones and ensuring a stable connection throughout your outdoor space.

Versatile Modes for Flexible Use - Our router supports a range of modes, including Mesh, AP, Router, Repeater, AP+Repeater,
and more, to meet your unique needs and adapt to various outdoor connection scenarios.
Whether you need to convert wired connections to wireless networks or enjoy seamless WiFi with a single network name and password,
our router has got you covered.

Long-Range Wireless Data Transmission - Specifically designed for outdoor use, AX3000 WiFi6 Extender can transmit wireless data
over distances of up to 3km/1.9 miles (in paired PtP or PtMP transmission), making it ideal for applications that require reliable long-range
connectivity. Built-in 12dBi directional antennas significantly improve transmission and reception performance,
ensuring a stable and secure connection even in challenging outdoor environments.

Specification
- Model: WL-WN573HP3
- Product Size: 24x24x7cm/9.4x9.4x2.8in
- PoE Converter Size: 4.4x3.7x2.2cm/1.7x1.5x0.9in
- Length: Ethernet Cable - 100cm/39.4in; Power Adapter Cable - 130cm/51.2in
- Product Weight: 1050g/37oz
- Standard: IEEE 802.11 ax/ac/a/n/g/b
- Frequency Band/Speed: 2.4GHz(573Mbps)+5GHz(2402Mbps)
- Wireless Security: WPA2-PSK, WPA2/WPA3-MIX
- Antennas: 4 x 12dBi Directional Antennas
- PAIR/RESET LED: Blue
- PoE Converter Status LED: GreenIn the Box
- 1 × AX3000 WiFi 6 Outdoor Access Point
- 1 × 54V Power Adapter
- 4 × Cable Ties
- 1 × PoE Converter
- 2 × Silicone Pads
- 1 × Ethernet Cable
- 1 × Main Body Holder
- 1 × PWM M4×8×8MM Screw
- 1 × Wrench
- 6 × KA M4×25×6MM Screws
- 1 × Quick Start Guide
- 6 × Φ8x25MM Screw PlugsWarm Tips
①The PoE converter is not waterproof, please install it indoors.
②Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m/328ft.
③Please install the product 2-3 meters above the ground for better performance.
④Under the mesh mode, WN573HP3 supports interconnection with WN586X3, WN583AX3 and WN573HX3.
⑤The real performance of the product may vary in accordance with different environmental conditions.6x 7dBi Omni Antennas(High-density), Wide Coverage/ up to 300M

Designed for Harsh Outdoor Conditions - IP67-rated waterproof housing that ensures continued operation on harsh
outdoor environments or in climates of extreme cold, heat or continuous moisture. Lightning protection and weatheproof
design ensure stable connection in harsh outdoor conditions. Note: The PoE part of the router is not waterproof.

Blazing-Fast WiFi 6 Speeds - Next-Gen Connectivity- The next generation of WiFi, complies with IEEE 802.11 ac/a/b/g/n standards.
Supports dual-band maximum speed up to 5GHz 2402Mbps and 2.4GHz 573Mbps, avoiding wireless interference
& congestion and offering lightning-fast Internet speed. With WAVLINK WN588HX3, you can enjoy HD videos,
smooth gaming, etc. even outdoors.

Seamless WiFi Roaming - Eliminate Dead Zones for Good - The 6x7dBi omni-directional antennas and high-power amplifiers
provide extreme WiFi coverage and penetration. Also supports Everything Mesh technology,
one-click brings more device connections, greatly expanding the WiFi coverage, and eliminating every network dead zone.

Versatile 5-in-1 Modes and More for Every Need- Supports Mesh, AP, Router, Repeater, AP+Repeater and other modes to meet your different
needs and apply to more outdoor connection scenarios. Router/AP mode is ideal for converting wired connections into wireless
networks, while under Mesh mode you can enjoy seamless WiFi with a single network name and password.

Powered by PoE and Flexible Installation - Supporting 802.3af/802.3at/48V PoE Power over Ethernet with the included PoE adapter,
this device offers flexible deployment and convenient installation with its mounting bracket design. It can be easily mounted on poles or walls.

Specification
- Model: WL-WN588HX3
- Product Size: 17x17.3x5.1cm/6.7x6.8x2in
- PoE Converter Size: 4.4x3.7x2.2cm/1.7x1.5x0.9in
- Length: Ethernet Cable - 100cm/39.4in; Power Adapter Cable - 130cm/51.2in
- Product Weight: 552g/19.5oz
- Standard: IEEE 802.11 ax/ac/a/n/g/b
- Frequency Band/Speed: 2.4GHz(573Mbps)+5GHz(2402Mbps)
- Wireless Security: WPA2-PSK, WPA2/WPA3-MIX
- Antennas: 6 x 7dBi Directional Antennas
- PAIR/RESET LED: Blue
- PoE Converter Status LED: GreenIn the Box
- 1 × AX3000 WiFi 6 Outdoor Access Point
- 4 × Plastic Cable Ties
- 1 × Main Body Holder
- 6 x 7dBi Antennas
- 1 × Wrench
- 1 × 54V Power Adapter
- 1 × PoE Converter
- 1 × Ethernet Cable
- 1 × PWM M3×5×6MM Screw
- 6 × KA M3×20×5.2MM Screws
- 6 × Φ6.5x25MM Screw Plugs
- 1 × Quick Start GuideWarm Tips
①The PoE converter is not waterproof, please install it indoors.
②Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m/328ft.
③Under the mesh mode, WN588HX3 supports interconnection with WN586X3, WN583AX3 and WN573HX3.
④The real performance of the product may vary in accordance with different environmental conditions.
