ASUSTOR LOCKERSTOR 2 GEN2+ AS6702T v2
2-Bay NAS | Dual 5GbE | Intel Quad-Core | 4GB DDR4 | 4× M.2 NVMe
Build fast, centralized storage for your home, creative workspace or business with the ASUSTOR LOCKERSTOR 2 Gen2+ AS6702T v2.
Designed for users who need more than basic network storage, the AS6702T v2 combines an Intel quad-core processor, dual 5-Gigabit Ethernet, four M.2 NVMe slots and expandable DDR4 memory in a compact 2-bay NAS.
DUAL 5-GIGABIT NETWORKING
The Gen2+ AS6702T v2 features two 5GbE Ethernet ports, providing significantly more network bandwidth than traditional Gigabit NAS systems.
Supported Ethernet speeds include:
• 5 Gigabit
• 2.5 Gigabit
• 1 Gigabit
• 100 Megabit
Ideal for high-speed file transfers, workstation backups, media libraries and modern multi-gigabit networks.
INTEL QUAD-CORE PERFORMANCE
Powered by the Intel Celeron N5105 quad-core processor, the LOCKERSTOR 2 Gen2+ delivers the processing capability needed for storage, backups, file sharing, multimedia and numerous NAS applications.
Base Frequency: 2.0 GHz
Burst Frequency: Up to 2.9 GHz
4GB DDR4 — EXPANDABLE TO 16GB
The system includes 4GB DDR4-2933 SO-DIMM memory and supports expansion to a maximum of 16GB, providing room to grow as your storage environment becomes more demanding.
FOUR M.2 NVMe SLOTS
In addition to its two primary SATA drive bays, the AS6702T v2 provides four M.2 slots supporting PCIe 3.0 NVMe SSDs.
This gives users additional flexibility for high-performance solid-state storage and supported caching configurations.
TWO SATA DRIVE BAYS
Install compatible:
• 3.5-inch SATA hard drives
• 2.5-inch SATA hard drives
• 2.5-inch SATA SSDs
The two-bay design provides flexible storage configurations while maintaining a compact desktop footprint.
RAID SUPPORT
Configure your storage according to your priorities with support for:
• Single Disk
• JBOD
• RAID 0
• RAID 1
RAID 1 provides the option to mirror data between two drives for additional drive-failure protection.
BUILT FOR CENTRALIZED STORAGE
Create your own centralized storage platform for:
Business File Storage
Keep important organizational data in one manageable location.
Computer Backups
Create centralized backup destinations for compatible computers and devices.
Creative Workflows
Store photography, video, project files and other large datasets.
Media Storage
Centralize your personal or professional media library.
Remote Access
Access supported NAS resources remotely when properly configured.
Team File Sharing
Create users, groups, permissions and shared storage locations for your organization.
CONNECTIVITY
The AS6702T v2 includes:
• 2× 5-Gigabit Ethernet
• 2× USB 10Gbps Type-A
• 1× USB 2.0 Type-A
• HDMI 2.0b
ASUSTOR DATA MASTER
ASUSTOR's ADM operating system provides the management platform for storage, users, applications, security, backups, remote access and additional NAS functionality.
TECHNICAL SPECIFICATIONS
Brand: ASUSTOR
Model: AS6702T v2
Series: LOCKERSTOR 2 Gen2+
Processor: Intel Celeron N5105
CPU: Quad-Core 2.0 GHz, up to 2.9 GHz
Memory: 4GB DDR4-2933
Maximum Memory: 16GB
SATA Bays: 2
M.2 NVMe Slots: 4
Networking: 2× 5GbE
RAID: Single / JBOD / RAID 0 / RAID 1
HDMI: HDMI 2.0b
Power Adapter: 65W
Dimensions: 6.44 × 4.25 × 9.06 inches
Weight: 4.41 lb
